Installation Guide
Model
SFP-SM1310
GE-SFP-ZX
GE-SX-MM850
GE-LX-SM1310
SFP-S4-R1000P1 v1
Mini-GBIC-GT
GE-SFP-GT
SFP-GT
Caution

For optical transceivers with a cabling distance equal to or greater than 40 km (131,233.6 ft.), install an
optical attenuator to avoid overload on the optical receiver when using short-distance SMF optical cables.

An optical transceiver is a laser transmitter. Do not look directly into the optical transceiver to prevent it
from burning your eyes.

To keep the optical transceiver clean, ensure that the unused ports remain capped.
Figure 6-5 BIDI Module Pairing Models
Rate/Distance
1000 Mbps/500 m (1640.42 ft.)
1000 Mbps/20 km (65616.80 ft.)
1000 Mbps/40 km (131233.60 ft.)
10000 Mbps/10 km (32808.4 ft.)
Connector Optical Cable
Type Type
LC SMF
LC MMF
LC MMF
LC SMF
LC SMF
RJ45
Ethernet Cat 5 (or higher) UTP or STP
cable
RJ45
Ethernet Cat 5 (or higher) UTP or STP
cable
RJ45
Ethernet Cat 5 (or higher) UTP or STP
cable
Pairing Model
GE-SFP-SX-SM1310-BIDI
GE-SFP-SX-SM1550-BIDI
GE-SFP-LX20-SM1310-BIDI
GE-SFP-LX20-SM1550-BIDI
GE-SFP-LH40-SM1310-BIDI
GE-SFP-LH40-SM1550-BIDI
XG-SFP-LR-SM1270-BIDI
XG-SFP-LR-SM1330-BIDI
37
Core
Max. Cabling
Specifications
Distance
(μm)
9/125 10 km (32,808.4 ft.)
50/125 550 m (1804.46 ft.)
50/125 550 m (1804.46 ft.)
9/125 10 km (32,808.4 ft.)
9/125 10 km (32,808.4 ft.)
100 m (328.08 ft.)
100 m (328.08 ft.)
100 m (328.08 ft.)
Appendix
