Ruijie Reyee RG-NBF6002M Installation Manual page 21

Installation Guide
3. Hardware Specifications of the MF6000M-16FS8GT2XS
Table 1-10 Hardware Specifications
Model
Ports
Supported Optical
Transceiver and
Cable Types
System LED
Hot Swapping
Power Consumption
Certification
Operating
Temperature
Storage Temperature
Operating Humidity
MTBF
Net Weight
Dimensions (W x D x
H)
of the MF6000M-16FS8GT2XS
MF6000M-16FS8GT2XS
16 x SFP/PON ports, 8 x 10/100/1000BASE-T RJ45 ports, and 2 x SFP+ ports
See 6.2 SFP and SFP+ Transceiver
supported.
The supported module types may update without prior notification. Please
contact Ruijie Networks for details.
SYS LED and Link/ACT LED
Not supported
< 36.4 W
CQC
0° C to 50° C (32° F to 122° F)
–40° C to +70° C (–40° F to +158° F)
10% to 90% RH (non-condensing)
> 200,000 hours
0.95 kg (2.09 lbs.)
227 mm x 210 mm x 40.3 mm (8.94 in. x 8.27 in. x 1.59 in.)
Modules. Copper cables are not
14
Overview
