Ruijie RG-NBS3300-8MG2XS-
P, NBS3300-16MG4XS-HP
Switches
Installation Guide
Document Version: V1.0
Date: July 22, 2024
Copyright © 2024 Ruijie Networks

Advertisement

loading
Need help?

Need help?

Do you have a question about the RG-NBS3300-8MG2XSP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ruijie RG-NBS3300-8MG2XSP

  • Page 1 Ruijie RG-NBS3300-8MG2XS- P, NBS3300-16MG4XS-HP Switches Installation Guide Document Version: V1.0 Date: July 22, 2024 Copyright © 2024 Ruijie Networks...
  • Page 2 Unless agreed upon otherwise in the contract, Ruijie Networks does not provide any explicit or implicit statements or warranties regarding the content of this document.
  • Page 3: Preface

    Preface Intended Audience This document is intended for:  Network engineers  Technical support and servicing engineers  Network administrators Technical Support  Ruijie Networks website: https://www.ruijienetworks.com/  Online support center: https://ruijienetworks.com/support  Case portal: https://caseportal.ruijienetworks.com  Community: https://community.ruijienetworks.com ...
  • Page 4 Note The manual provides configuration information, including models, port types, and command line interfaces, for reference purposes only. In the event of any discrepancy or inconsistency between the manual and the actual version, the actual version shall take precedence.
  • Page 5: Table Of Contents

    Contents Preface ..............................I 1 Introduction ............................1 1.1 About the RG-NBS3300 Series ....................1 1.2 Package Contents........................1 1.2.1 RG-NBS3300-8MG2XS-P Package Contents ............... 1 1.2.2 RG-NBS3300-16MG4XS-HP Package Contents ............2 1.3 Product Appearance ........................2 1.3.1 RG-NBS3300-8MG2XS-P Product Appearance ............2 1.3.2 RG-NBS3300-16MG4XS-HP Product Appearance ............
  • Page 6 2.2.4 Temperature and Humidity Requirements ..............14 2.2.5 Cleanliness Requirements ................... 15 2.2.6 Grounding Requirements ..................... 15 2.2.7 Anti-interference Requirements ................... 16 2.2.8 Surge Protection Requirements................... 16 2.2.9 Installation Site Requirements ..................16 2.3 Rack Requirements ......................... 17 2.4 Tools ............................18 3 Installing the Switch .........................
  • Page 7 4.1 Setting Up the Configuration Environment ................25 4.1.1 Connecting the PC to the Switch ................. 25 4.1.2 Logging In to the Web Interface ................... 25 4.2 Powering On ..........................25 4.2.1 Checklist Before Power-on ..................25 4.2.2 Checklist After Power-on ..................... 25 5 Common Troubleshooting ........................
  • Page 9: Introduction

    Introduction About the RG-NBS3300 Series The RG-NBS3300 series switches are next-generation 2.5G Ethernet access switches launched by Ruijie Networks. These devices are designed for ease of use and can be configured in the cloud. The cost-effective 2.5G bandwidth and high-power PoE output fully meet the access requirements in high-bandwidth and high- density wireless scenarios, maximizing the wireless performance of Wi-Fi 6 and Wi-Fi 7 access points.
  • Page 10: Rg-Nbs3300-16Mg4Xs-Hp Package Contents

    Installation Guide Introduction Item Quantity Remarks Yellow/green ground wire Power cord retention clip Note The package contents above are intended to provide a general overview, and are subject to the terms of the order contract. Check your goods carefully against the order contract. If you have any questions, please contact the distributor.
  • Page 11 Fast blinking green (10 times per second): The system is starting or upgrading. System status LED Slow blinking green (2 times per second): The device is operating normally, but is not connected to Ruijie Cloud. Solid green: The device is operating normally, and is connected to Ruijie...
  • Page 12 Installation Guide Introduction Cloud. Blinking yellow: A system alarm is reported due to insufficient total available PoE power. Blinking red: The system is faulty due to a switch loop or PoE failure. Off: The electrical port status LED indicates the Link/Ack status. LED Mode LED Solid green: The electrical port status LED indicates the PoE power supply status.
  • Page 13: Rg-Nbs3300-16Mg4Xs-Hp Product Appearance

    Slow blinking green (2 times per second): The device is operating normally, System LED but is not connected to Ruijie Cloud. Solid green: The device is operating normally, and is connected to Ruijie Cloud. Blinking yellow: The system has an alarm due to insufficient total available...
  • Page 14 Installation Guide Introduction PoE power. Blinking red: The system is faulty due to a switching loop or PoE failure. Off: The electrical port status LED indicates the Link/Ack status. LED Mode LED Solid green: The electrical port status LED indicates the PoE power supply status.
  • Page 15: Technical Specifications

    Caution Cable Types The supported optical transceiver types may update without prior notification. Contact Ruijie Networks for details. AC input: Rated voltage range: 100 V AC to 240 V AC Max. voltage range: 90 V AC to 264 V AC...
  • Page 16 Installation Guide Introduction Input Parameter of ≤ 3.5 mA the Ground- Leakage Current Supported IEEE 802.3af (PoE) and IEEE 802.3at (PoE+) Ports 1–8 are PoE/PoE+ ports, and each port supports a maximum of 30 W PoE power supply. Maximum PoE/PoE+ output power: 240 W 1 2-,3 6+ PoE Power Pins Press and hold the button for less than 2 seconds: The system restarts.
  • Page 17: Rg-Nbs3300-16Mg4Xs-Hp Technical Specifications

    The switch has a built-in lithium battery to keep the real-time clock running when external power source is unavailable. To replace the lithium battery, please contact Ruijie Networks Customer Service Technical Support to have it replaced with a lithium battery of the same specifications.
  • Page 18 Installation Guide Introduction Input Parameter of ≤ 3.5 mA the Ground- Leakage Current Supported IEEE 802.3af (PoE), IEEE 802.3at (PoE+), and IEEE 802.3bt (PoE++) Ports 1–4 support PoE/PoE+/PoE++ power supply, with a maximum power of 90 W per port. Ports 5 to 16 are PoE/PoE+ ports, and each port supports a maximum of 30 W PoE power supply.
  • Page 19 The switch has a built-in lithium battery to keep the real-time clock running when external power source is unavailable. To replace the lithium battery, please contact Ruijie Networks Customer Service Technical Support to have it replaced with a lithium battery of the same specifications.
  • Page 20: Preparing For Installation

    Installation Guide Preparing for Installation Preparing for Installation Safety Precautions Note To avoid bodily injury and device damage, carefully read the safety precautions before you install the device. The following safety precautions may not cover all possible dangers. 2.1.1 General Safety Precautions ...
  • Page 21: Esd Safety

    Installation Guide Preparing for Installation  Select the right leakage protector (also called "leakage current switch" or "leakage current breaker") for the power supply system. This device automatically disconnects the power supply in the event of leakage and the risk of electric shock. A leakage protector should meet the following requirements: ○...
  • Page 22: Installation Environment Requirements

    Installation Guide Preparing for Installation Figure 2-1 Laser Product Warning Warning Do not approach or look directly into any optical port under any circumstances. This may cause permanent damage to your eyes. Installation Environment Requirements Install the device indoors to ensure its normal operation and prolonged service life. The installation site must meet the following requirements.
  • Page 23: Cleanliness Requirements

    Installation Guide Preparing for Installation Note The operating temperature and humidity of the device are measured 1.5 m (59.06 in.) above the floor and 0.4 m (15.75 in.) before the rack when there is no protective plate in front or at the back of the rack. 2.2.5 Cleanliness Requirements Dust poses a major threat to the operational safety of the device.
  • Page 24: Anti-Interference Requirements

    Installation Guide Preparing for Installation  Secure Grounding Ensure that the rack and power distribution device are securely grounded if the device uses the AC power supply. Failure to do so may result in an increased risk of electric shock, particularly when the insulation resistance between the power supply inside the device and the chassis decreases.
  • Page 25: Rack Requirements

    Installation Guide Preparing for Installation chassis. Maintain a minimum clearance of 150 mm (5.91 in.) around the air outlets for heat dissipation. You are advised to install the device in a standard 19-inch rack, or place it on a clean workbench. In hot areas, air-conditioning is recommended.
  • Page 26: Tools

    Installation Guide Preparing for Installation Tools Table 2-3 Tools Phillips screwdriver, power cords, Ethernet cables, cage nuts, diagonal pliers, and cable Common Tools ties Special Tools ESD gloves, wire strippers, crimpers, RJ45 connector crimping pliers, and wire cutters Meters Multimeter Relevant PC, display, and keyboard Devices...
  • Page 27: Installing The Switch

    Installation Guide Installing the Switch Installing the Switch Caution Before installing the device, ensure that all the requirements described in Chapter 2 are met. Installation Procedure Figure 3-1 Installation Flowchart Prepare for installation Install the Axis Device in the specified Location Connect the grounding Axis Cable CONNECT the power cord Connect the ethernet Axis Cables...
  • Page 28: Installing The Device In The Specified Location

    Installation Guide Installing the Switch Installing the Device in the Specified Location 3.3.1 Precautions The installation method of the RG-NBS3300-8MG2XS-P and RG-NBS3300-16MG4XS-P switches is the same. Unless otherwise specified, the RG-NBS3300-16MG4XS-P switch is used as an example. Pay attention to the following during installation: ...
  • Page 29: Installing The Switch On A Workbench

    Installation Guide Installing the Switch Step 2: Place the switch horizontally in the rack. Use the supplied M6 screws and matching cage nuts to secure the other end of the mounting bracket to the front mounting rail of the rack, as shown in Figure 3-3 and Figure 3-4.
  • Page 30: Connecting The Grounding Cable

    Installation Guide Installing the Switch Figure 3-5 Installing the Switch on a Workbench-1 Step 2: Place the switch on a workbench and ensure that there is adequate airflow around the switch for proper ventilation, as shown in Figure 3-6. Figure 3-6 Installing the Switch on a Workbench-2 Note The switch should be installed and operated in a stationary position.
  • Page 31: Connecting Cables

    Installation Guide Installing the Switch  Do not use bare wire.  The resistance between the chassis and the ground should be less than 1 ohm. Connecting Cables This chapter describes how to connect the power cord, Ethernet cables, and optical cables. 3.5.1 Precautions ...
  • Page 32: Verifying The Installation

    Installation Guide Installing the Switch (3) Bind the power cord closely along the bottom of the chassis in a straight line wherever possible. Verifying the Installation Caution Turn off the power to prevent personal injury and damage to components caused by incorrect connection. ...
  • Page 33: Verifying The Operating Status

    Installation Guide Verifying the Operating Status Verifying the Operating Status Setting Up the Configuration Environment 4.1.1 Connecting the PC to the Switch  Connect one RJ45 connector of the Ethernet cable to the Ethernet port of the PC.  Connect the other RJ45 connect of the Ethernet cable to the MGMT port of the switch. 4.1.2 Logging In to the Web Interface (1) Configure your PC with an IP address in the subnet 10.44.77.XXX (1-255, excluding 200).
  • Page 34: Common Troubleshooting

    The device is not working properly Check the device installation Check the power connection Check the LEDs status of the device Check the cable connection Contact technical support of Ruijie Networks Troubleshooting Fault Symptom Possible Cause Solution The login password...
  • Page 35 Installation Guide Common Troubleshooting or transmitting The port has special configuration, Check that the port configuration has frames which does not adapt to the the common working mode with the working mode of the connected connected switch. switch. The receiving and transmitting Exchange the transmitting and ends are connected incorrectly.
  • Page 36: Appendix

    Hardware Installation and Reference Guide Appendix Appendix Appendix A: Ports, Connectors, and Media 6.1.1 1000BASE-T/100BASE-TX/10BASE-T Ports The 1000BASE-T/100BASE-TX/10BASE-T port is a 10/100/1000 Mbps auto-negotiation port that supports auto medium-dependent interface/MDI crossover (MDI/MDIX). RJ45 connectors are supported. Compliant with IEEE 802.3ab, the 1000BASE-T port requires 100-ohm Category 5 or Category 5e unshielded twisted pair (UTP) or shielded twisted pair (STP) (recommended) with a maximum distance of 100 meters (328 feet).
  • Page 37: Sfp And Sfp+ Ports

    Hardware Installation and Reference Guide Appendix 4, 5, 7, 8 Not Used Not Used Figure 6-2 shows wiring of straight-through and crossover cables for the 100BASE-TX/10BASE-T port. Figure 6-2 100BASE-TX/10BASE-T Twisted Pair Connections 6.1.2 SFP and SFP+ Ports SFP and SFP+ ports are also called optical ports, which require optical transceivers or copper SFP transceivers. ...
  • Page 38: Appendix B: Sfp And Sfp+ Modules

    (Mini-GBIC-GT transceivers) are supported. The following models and technical specifications of some SFP and SFP+ transceivers are provided for your reference. For details about the technical specifications, see Ruijie Optical Module Hardware Installation and Reference Guide. 6.2.1 SFP Modules...
  • Page 39 Hardware Installation and Reference Guide Appendix Intensity of Intensity of Optical Transmitted Received Light Wavelength Model Cable Light (dBm) (dBm) (nm) (Yes/No) type –9.5 –3 –17 GE-SFP-SX –9.5 –3 –20 –3 GE-SFP-LX 1310 –9.5 –3 –17 SFP-MM850 –9.5 –3 –20 –3 SFP-SM1310 1310...
  • Page 40 Hardware Installation and Reference Guide Appendix Core Connector Optical Cable Max. Cabling SFP Model Specifications Type Type Distance (μm) GE-SFP-LH40-SM1550-BIDI 9/125 40 km (131233.60 ft) MINI-GBIC-ZX50-SM1550 9/125 50 km (164042 ft) MINI-GBIC-ZX80-SM1550 9/125 80 km (262467.19 ft) 100 km (328083.99 MINI-GBIC-ZX100-SM1550 9/125 62.5/125...
  • Page 41: Sfp+ Modules

    Hardware Installation and Reference Guide Appendix 6.2.2 SFP+ Modules Table 6-6 Models and Specifications of SFP+ Modules Intensity of Intensity of Optical Transmitted Light Received Light Wavelength Cable Model (dBm) (dBm) (nm) (Yes/No) Type XG-SFP-SR- –7.3 –1 –9.9 –1 MM850 –7.3 –1 –9.9...
  • Page 42  SFP+ transceiver types are subject to change without prior notice. For more accurate information about the optical transceivers, contact Ruijie marketing or technical support personnel.  The DDM function of AOC cables does not report the transmit power. The TX power is displayed as N/A.
  • Page 43 Hardware Installation and Reference Guide Appendix XG-SFP-LR-SM1330- 10 km 9/125 BIDI (32,808.40 ft) 10 km XG-SFP-LR-SM1310 9/125 (32,808.40 ft) 40 km XG-SFP-ER-SM1550 9/125 (131,233.60 ft) 80 km XG-SFP-ZR-SM1550 9/125 (262,467.19 ft) 200 (OM1) 33 m (108.27 ft) 62.5/125 26 m (85.30 ft) 300 m (984.25 XS-SFP-SR 2000 (OM3)
  • Page 44: Appendix C: Lightning Protection

    Hardware Installation and Reference Guide Appendix Appendix C: Lightning Protection 6.3.1 Installing an AC Power Arrester (Lightning Resistance Socket) When an AC power cord is introduced from outdoors and directly connected to the power port of the device, the AC power port must be connected to an external lightning protection power strip to protect the device against lightning strokes.
  • Page 45: Installing The Ethernet Port Arrester

    Hardware Installation and Reference Guide Appendix polarity of the arrester power cord should be reversed. In this case, you should open the power arrester and rectify the polarity of the connection. If the indicator is still red, the arrester's PE terminal is not grounded. 6.3.2 Installing the Ethernet Port Arrester Connect an Ethernet port arrester to the device to prevent the damage by lightning before connecting an outdoor...
  • Page 46 Hardware Installation and Reference Guide Appendix Pay attention to the following situations during the installation to avoid influencing the performance of the Ethernet port arrester:  Reversed installation direction of the arrester. Connect the external network cable to the "IN" end and connect the Ethernet port of the device to the "OUT"...
  • Page 47: Appendix D: Cabling Recommendations

    Hardware Installation and Reference Guide Appendix Appendix D: Cabling Recommendations When the device is installed in a standard 19-inch rack, secure the cables around the cable management brackets. Adopt top cabling or bottom cabling according to the actual situation in the equipment room. All cable connectors used for transit should be placed at the bottom of the cabinet rather than be exposed outside of the cabinet.
  • Page 48 Hardware Installation and Reference Guide Appendix Figure 6-6 Binding Cables (I)  Cables of different types (such as power cords, signal cables, and ground cables) should be separated in cabling and bundling. Mixed bundling is disallowed. When they are close to each other, you are advised to adopt crossover cabling.
  • Page 49 Hardware Installation and Reference Guide Appendix  When cables need to be bent, please bundle them up but do not tie them where the cables will be bent, as shown in Figure 6-8. Figure 6-8 Binding Cables (III)  Cables not to be assembled or remaining parts of cables should be folded and placed in a proper position of the rack or cable trough.
  • Page 50 Hardware Installation and Reference Guide Appendix  Nut  Flat washer  Hard power cords should be fastened in the terminal connection area to prevent stress on terminal connection and cable.  Do not use self-tapping screws to fasten terminals. ...
  • Page 51: Appendix E: Equipment Room Site Selection

    Hardware Installation and Reference Guide Appendix Appendix E: Equipment Room Site Selection  The equipment room should be at least 5 km (3.11 miles) away from heavy pollution sources, such as the smelter works, coal mine, and thermal power plant. The equipment room should be at least 3.7 km (2.30 miles) away from medium pollution sources, such as the chemical factory, rubber factory, and electroplating factory.
