S T E P 3
INSTALL REAR
DERAILLEUR
Move to the rear of the bike and cut off any zip-ties
or packaging from the rear derailleur and chain.
PRO BUILD: Before installing your derailleur ensure
that the Hall lock lever is in the unlocked position (A).
PRO & EXPERT BUILD: Using a 5mm Allen key,
thread the derailleur into the derailleur hanger/frame
(B). At this point be careful that the 'B plate' is
positioned correctly so that it sits on the lat notch on
the hanger (C). With the torque wrench tighten the
main derailleur bolt to 10-12Nm (D).
PRO BUILD: The TRP Derailleur doesn't have a
cage lock (E) move on to installing rear wheel.
EXPERT BUILD: Holding the bottom of the SRAM
GX derailleur cage pivot the derailleur toward the
front of the bike. There will be some resistance from
the spring, so be careful that it doesn't spring back
into position. When it won't go any further forward,
and in a near vertical position, press the small button
with a padlock logo printed on it. This is the 'Cage
Lock'. While holding the lock button, gently release
the derailleur cage. The derailleur should now be
locked in position (F), which will make it easier for
you to install the rear wheel.
