M 1
PARTS
LISTING
15
12
41
21
8
39
41
5
41
35
14
41
3
24
34
52
41
10
41
51
48
49
9
13
1 40
45
10
40
2 40
28
10 40
13
56
53
29
50
27 26
39
8
12
15
41
4
11
41
22
8
39
25
44 31
33
18
19
42
17
2
32
6
38
37
7
23
ITEM
1 Hanger
2 Hanger Bolt
3 Washer 15 x 21 x 1
4 Lower Shock Link
5 Top Shock Link
6 Idler Pulley
7 Bolt
43
8 Bolt
9 Rear Axle
10 Spacer 15.2 x 18 x 2.1
11 Spacer 15.2 x 18 x 20
12 Washer 15.1 x 24 x 2.5
13 Bolt
14 Bolt
15 Bolt
16 Collet Bolt
17 Idler Plate
47
18 Idler Bracket
19 Idler Washer
20 Cone Adjuster
36
21 Rocker Link
46
22 Push Rivet
16
23 Zip Tie
20
30
24 Rear Fender
25 Skid Plate
26 Shifting Housing,
Cable Protector
27 Braking Housing,
Cable Protector
28 Clip Plastic
29 Seat Clamp
30 SHCS M6 x 25
31 FHCS M4 x 0.7
32 Torx M5 X 16
33 Low-Profile, M5 x 20
34 Low-Profile, M5 x 10
35 Bolt
36 Bolt
37 Retaining Ring
38 Bearing 6902
39 Bearing 6903
PART No. DESCRIPTION
130790 Hanger Derailleur M1 Forged 275C Blk
130798 RD, Hanger Bolt
130921 Washer 15 x 21 x 1
130922 Lower Shock Link, M1
130925 Top Shock Link Dual Position, M1
130926 Idler Pulley 14T
130927 Bolt M15 x 1 x 14.4, Idler
130930 Bolt M17 X 1.5, Main Frame
130931 DH Axle, Rear M12 x 1.0
130934 Spacer 15.2 x 18 x 2.1
130935 Spacer 15.2 x 18 x 20
130936 Washer 15.10 x 24 x 2.5
130937 Bolt M15 X 1.25 x 25
130938 Bolt M15 X 1.25 x 34
130939 Bolt M15 X 1.25 x 35
130940 Bolt M15 X 1.25 x 53
130941 Idler Plate_Gen3
130942 Idler Bracket_Gen3
130943 Idler Washer, 28.2 x 17.4 x 3
130944 Collet Cone Adjuster, 18.5 OD x 9.5mm Tall
M1 Rocker Link One Piece,
130945
Left and Right Connected, M1
140038 Push Rivet SR-0817BK
140053 Zip Tie, Lower Cable Guide
140093 Rear Fender, M1 DH
Skidplate M1 Blk
140099
Jagwire CCG017-BJ on Shifting Housing,
140105
Jagwire CCG025-BJ on Braking Housing
140106
310001 Clip for Single Guide Plastic
340339 Seat Clamp, GW #CSC0040
410039 SHCS, Socket Head, M6 x 25
410083 FHCS, Flat Head, M4 x 0.7 x 8, Black Oxide
410091 Screw Flat Head Torx M5 X 0.8 X 16
410093 Low-Profile Socket Head Screw, M5 x 0.8 x 20 1
410094 Low-Profile Socket Head Screw, M5 x 0.8 x 10 1
410095 Bolt SHCS M8 x 1.25 x 32
410096 Bolt SHCS M8 x 1.25 x 55
420041 Idler Retaining Ring
430009 Bearing 6902-LLU-MAX, 15 x 28 x 7
430069 Bearing 6903 LLU MAX-E 17 X 30 X 7/10
QTY. TORQUE SPEC.
1 N/A
1 11 Nm / 100 in-lbs
1 N/A
1 N/A
1 N/A
1 N/A
1 16 Nm / 140 in-lbs
3 22.5 Nm / 200 in-lbs
1 11 Nm / 100 in-lbs
3 N/A
1 N/A
2 N/A
2 20 Nm / 180 in-lbs
1 20 Nm / 180 in-lbs
2 20 Nm / 180 in-lbs
1 7 Nm / 60 in-lbs
1 N/A
1 N/A
1 N/A
1 N/A
1 N/A
1 N/A
7 N/A
1 N/A
1 N/A
1 N/A
1 N/A
5 N/A
1 6-8 Nm / 53-70 in-lbs
1 14 Nm / 125 in-lbs
2 3 Nm / 26 in-lbs
1 8-10 Nm / 70-90 in-lbs
4 Nm / 35 in-lbs
4 Nm / 35 in-lbs
1 10 Nm / 90 in-lbs
1 10 Nm / 90 in-lbs
1 N/A
1 N/A
3 N/A
