S T E P 1 3
REAR SUSPENSION SETUP
First check the spring rate-chart on the bottom of this page to make sure that the
spring fitted on your FOX Performance Elite DHX2 Coil shock is within range for your
rider weight. If the spring is too hard or too soft you will need to change it. Please see
our Tech Videos section on our website to see how to change the coil on your shock.
S H OC K : F OX FACTORY D HX2 C O IL SH OC K
SUGGESTED STARTING POINTS FOR SETTING UP YOUR SHOCK
RIDER COIL LOW
WEIGHT SPRING SPEED
(LBS/KGS) (LBS)
COMPRESSION
15-16
100 / 45 250
100 / 45 275 15-16
110 / 50 300 14-15
110 / 50 325 14-15
120 / 54 350 13-14
120 / 54 375 13-14
130 / 59 400
12-13
140 / 64 425 11-12
150 / 68 450 10-11
160 / 73 475 9-10
170 / 77 500 8-9
180 / 82 525 8-9
190 / 86 550 6-7
200 / 91 575 5-6
210 / 95 600 5-6
220 / 100 625 4-5
230 / 104 650 4-5
240 / 109 675 3-4
250 / 113 2-3
700
SPRING RATES FITTED AS STANDARD
SMALL MEDIUM
450LBS 500LBS
40
M1 PRO
HIGH
HIGH
LOW
SPEED SPEED SPEED
REBOUND
REBOUND
COMPRESSION
7-8 9-10
7-8
7-8 8-9
6-7
6-7 7-8
6-7
6-7 7-8
6-7
5-6 6-7
5-6
5-6 6-7
5-6
5-6 5-6
5-6
4-5 5-6
4-5
4-5 4-5
4-5
3-4 4-5
3-4
3-4 3-4
3-4
2-3 3-4
2-3
2-3 2-3
2-3
1-2 2-3
1-2
1-2 2-3
1-2
0-1 1-2
0-1
0-1 1-2
0-1
0-1 1-2
0-1
0-1 0-1
0
FR AME SIZES
LARGE EXTRA LARGE
550LBS 600LBS
SETTING REAR SHOCK SAG
The optimal sag on your rear shock is 20-30% of the piston's move-ment inside the
shock body (stroke). The distance between the two shock mounting bolts (eye-to-
eye) without a rider on the bike is 212mm progressive & 203mm Linear.
In the Progressive position your optimal sag range is 42.4mm (20%) to 63.6mm
(30%). In the Linear position your optimal sag range is 40.6mm (20%) to 60.9 (30%).
COMPRESSION ADJUSTMENTS
High-speed compression (HSC) adjustment is useful to control
shock performance during bigger hits, landings, and square-edged
bumps. Low-speed compression (LSC) adjustment is useful to
control shock performance during rider weight shifts, G-outs, and
other slow inputs. Starting closed to adjust turn counter-clockwise.
REBOUND
The low speed rebound adjustment is accessed through the 3mm
ADJUSTMENTS
Allen head adjuster, located in the red dial. The high speed
compression is accessed through 6mm Allen head adjuster,
Low-speed rebound (LSR)
located in the blue dial. The high speed rebound adjustment is
adjustment is useful to
accessed with a 2mm Allen key or by hand.
control shock performance
during brake bumps,
technical climbing, and
off-camber cornering, when
extra traction is needed.
Starting closed to adjust turn
counter-clockwise.
High-speed rebound
(HSR) adjustment is
useful to allow the shock
to recover from bigger hits
and square-edged bumps
quickly enough to ab-sorb
consecutive hits. The
HSR has 8 total clicks of
adjustment. When viewing
the shock from the end with
the HSR adjuster, rotating
the HSR ad-juster clockwise
Proper set up and tuning can vary from shock to
slows down HSR. Rotating
shock. Please consult the FOX manual included
the HSR adjuster counter-
with your bike for complete information about set up,
clockwise speeds up HSR.
tuning and general maintenance or visit ridefox.com
LOW SPEED
REBOUND DIAL
HIGH &
LOW SPEED
COMPRESSION
DIALS
HIGH SPEED REBOUND DIAL
41
