S T E P 1 3 C O N T I N U E D . . .
In order to remove the rear shock, move the shock
backwards and up towards the saddle (E).
LARGE & EXTRA LARGE FRAME - Pull the shock
forward and twist to remove the the shock from the
shock cavity to ensure there is no paint damage.
Connect the shock pump to the shock (F) and set to
the recommend air pressure from Fox, reference page
42 for shock settings. Once set reinstall the shock
back into the the bike by inserting the shock into the
shock cavity (G).
LARGE & EXTRA LARGE FRAME - reinsert the
shock into the shock cavity in the same manner that it
was removed.
Set the shock into your preferred progression position
G H
and reinstall the rearward & forward shock mounting
bolt 6mm Allen key (H).
