AMP Research PowerStep 76239-01A Installation Manual page 9

Prepare large tie-wraps for mounting Power Step
Controller. Loosely loop tie-wraps around large
bundle of wires behind battery in engine
compartment.
13
22
Remove fuse from Power Step Wire Harness.
4
24
Locate large rubber wire boot on driver
side firewall as shown below. Slice small
opening as shown below to run trigger
wires through.
25
www.amp-research.com
A M P R E S E A R C H P O W E R S T E P – D O D G E R A M
T M
Insert controller into tie-wrap loops and cinch down
securely. The tie-wraps should cinch down into
channels on controller surface.
5
23
Connect power leads from Controller, Red to
positive battery terminal and Black to the vehicle
body ground as shown.
9/15
4
10mm
IM76239 rev 01.15.18
