AMP Research PowerStep 76239-01A Installation Manual page 5

NOTE: 1500 RAM Only! Powerstep installations require additional steps and
come with the required additional hardware. Please read and carefully follow the
instructions in Step 1 for your vehicle model.
harness plug and then proceed with the Power Step installation.
On Drivers side of vehicle towards front of body remove harness bracket with 10mm socket or wrench. Re-
move plug from bracket. And replace with supplied bracket using two of the three factory screws.
1
While holding brake cable adjustment nut with
wrench (located on driverside along frame, towards
the rear), loosen brake cable to allow for slack.
Mark position of nut before loosening.
2
Remove brake cable guide from frame by depressing
locking tabs and sliding guide out through hole.
Unthread brake cable from frame mount.
4
www.amp-research.com
A M P R E S E A R C H P O W E R S T E P – D O D G E R A M
T M
Follow Steps 1-5 to relocate brake cable and wire
For Ram 2500/3500 Skip to step 6.
After gaining enough slack, detach brake cable as
shown below. This detachment point is located just
to the rear of the adjustment nut.
3
13mm
Attach brake cable guide to supplied Brake Cable
Bracket (27) and mount bracket with supplied
hardware. Reattach brake cable and readjust brake
cable adjustment nut to original position.
24
5
5/15
27
26
25
IM76239 rev 01.15.18
13mm
13mm
