APPLICATION
Ford F-250 / F-350 / F-450 Regular Cab
Ford F-250 / F-350 / F-450 Super Cab
Ford F-250 / F-350 / F-450 Crew Cab
*Modification required to running board assembly. See Item 1 on page 3.
AMP RESEARCH TECH SUPPORT 1-888-983-2204 (Press 2) Monday - Friday, 7:00 AM - 5:00 PM PST
Invented, engineered and manufactured exclusively by AMP Research in the USA. May be covered by one of the following patents:
6,641,158; 6,830,257; 6,834,875; 6,938,909; 7,055,839; 7,380,807; 7,398,985; 7,584,975 ©2012 AMP Research. All rights reserved.
Printed in USA.
www.amp-research.com
I N S T A L L A T I O N G U I D E
LENGTH
*
(48")
*
(60")
(79")
1/10
MODEL YR
2008-2016
2008-2016
2008-2016
INSTALLATION TIME
2-3 Hours
Professional installation recommended
SKILL LEVEL
2
1
4= Experienced
TOOLS REQUIRED
q Safety goggles
q Measuring tape
q Flat blade screwdriver
q Phillips head screwdriver
q 13mm socket
q 8mm socket
q Ratchet wrench and extension
q Wire crimpers
q Wire stripper / cutter
q 3/16" hex key (allen wrench)
q 4mm hex key (allen wrench)
q Electrical tape
q Silicone caulking (sealer)
q 25/64" Drill Bit
q 9/32" Drill Bit
WARRANTY
5-Year Limited Warranty
IM76234 rev 11.20.19
PART #
76234-01A
76234-01A
76234-01A
3
4
Advertisement
Related Manuals for AMP Research Power Step 76234-01A
Summary of Contents for AMP Research Power Step 76234-01A
- Page 1 AMP RESEARCH TECH SUPPORT 1-888-983-2204 (Press 2) Monday - Friday, 7:00 AM - 5:00 PM PST Invented, engineered and manufactured exclusively by AMP Research in the USA. May be covered by one of the following patents: 6,641,158; 6,830,257; 6,834,875; 6,938,909; 7,055,839; 7,380,807; 7,398,985; 7,584,975 ©2012 AMP Research. All rights reserved.
-
Page 2: Exploded View
A M P R E S E A R C H P O W E R S T E P – F O R D S U P E R D U T Y INSTALLATION GUIDE Attaching motor to linkage assembly The motors must be attached to the linkage assemblies before continuing the installation process. - Page 3 A M P R E S E A R C H P O W E R S T E P – F O R D S U P E R D U T Y Note: Some Applications require modification. Application Cut Length Crew Cab 79”...
- Page 4 A M P R E S E A R C H P O W E R S T E P – F O R D S U P E R D U T Y PARTS LIST AND HARDWARE IDENTIFICATION Hex head screw Conical Bolt Button head - M10 Socket cap screw...
-
Page 5: Idler Assembly
A M P R E S E A R C H P O W E R S T E P – F O R D S U P E R D U T Y Driver Side Shown Driver Side Use second and last set of mounting holes, counting from the front. - Page 6 A M P R E S E A R C H P O W E R S T E P – F O R D S U P E R D U T Y Secure controller to vehicle wire loom beside Remove fuse from harness.
- Page 7 A M P R E S E A R C H P O W E R S T E P – F O R D S U P E R D U T Y Wire OBD II connector with Posi-Splice and plug into port.
- Page 8 A M P R E S E A R C H P O W E R S T E P – F O R D S U P E R D U T Y Plug in motors (both sides). Route remaining LED Secure wires and replace kick panel and sill plate.
- Page 9 A M P R E S E A R C H P O W E R S T E P – F O R D S U P E R D U T Y Drill a 9/32” hole through the pinch weld at marked Insert grommet into drilled holes.
-
Page 10: Final System Check
A M P R E S E A R C H P O W E R S T E P – F O R D S U P E R D U T Y Check that all doors activate the Power Step and the LED Lights work when doors open and close. - Page 11 • Registration helps us keep you up to date on product information and offers To view other Amp Research products that may be offered for your vehicle. Please visit: www.amp-research.com Rev 01.05.21...
- Page 12 5-YEAR LIMITED WARRANTY AMP RESEARCH warrants this product to be free from defects in material and workmanship for FIVE (5) YEARS FROM DATE OF PURCHASE, provided there has been normal use and proper maintenance. This warranty applies to the original purchaser only.
