Install boards: Slide mounting T-Nut of board into position and attach to linkages. Shift board
forward as much as possible for proper clearance. The end of board/end cap will nest into linkage
lower mount 1/2" when positioned correctly. With doors open Reinstall fuse.
extended position step on boards to seat linkages. Walk the length of the
board taking bouncing steps. DO NOT JUMP ON BOARD! Verify that board
end caps do not contact the pinch weld.
head screws at pinch weld. Walk the length of the board and apply weight to the center of
the board and while applying weight retighten button head screws at pinch weld.
28
40
32
With linkage resting square on the hex bolts Using a
30
3/16" Drill bit, drill both upper holes in linkage through
sheetmetal. After drilling apply paint to holes to
prevent rusting.
41
www.amp-research.com
A M P R E S E A R C H P O W E R S T E P – D O D G E R A M
T M
If Endcaps make contact loosen 4 button
4
28
32
Torque to 10 ft-lbs. (13.5 Nm)
Using a Rivet Gun install rivets.
33
42
3/16"
14/15
With boards in
IM76239 rev 01.15.18
