Printer Commands
5.2.1.7 Software Switch #7
^AB ^D COMMAND
XX 27 Change SW7: Software Switch #7.
^AB12345678 (each bit is represented by a numeric position number)
Position:
123 Select STL Stock Class:
These bits are used to select the class of the stock to be used according to
the following bit pattern:
100 – Standard
010 – Cinema Ticket
011 – Magnetic Card (fixed length = 3.375 inch, width = 2.116 inch)
001 - Wristbands
456 Select STL Stock Width:
These bits are used to select the width of the stock (in inches) to be used
according to the following bit pattern:
000 – 1.00
100 – 1.328
010 – 2
110 – 2.125
001 – 2.5
101 – 2.75
011 – 3.25
111 – 4
7 Disable System Parameter Saving: When enabled, the printer will not save
the non-volatile system parameters on power downs. The ^A1^D143 will
continue to save system parameters.
8 Finish Mode: When enabled, the printer will finish printing the current label
as far as it can after a stock out error. The change will take place after a power
cycle or after the restart command. When a stock out occurs the printer will
finish printing the entire label if the LSY is less than the dot-to-gap distance. If
greater, it will continue printing for a distance equal to the dot to gap distance
OR until the label finishes; which ever comes first. The dot-to-gap value is
configurable using the D158 command. The error will be acknowledged at the
end of printing. This will work with all media (continuous, black line, and gap).
5-12
1 = Disable system parameter saving
0 = Enable system parameter saving
1 = Enable Finish Mode
0 = Disable Finish Mode
