Microcom 238B Operator's Manual page 60

Printer Commands
low
355
458
559
635
686
762
864
965
1067
1130
1181
1270
1371
1828
Autoheader User Mode
The Autoheader User Mode operates in a similar fashion to the Table Mode,
but uses a table that the user creates. The user can have up to three stock
ranges within the table (3, 6, or 9 values).
To enter stock ranges use the ^D170 command as follows.
The 1st range is entered like this:
^A1^D170[CR]Range1LowThreshold[CR]
^A2^D170[CR]Range1Target[CR]
^A3^D170[CR]Range1UpperThreshold[CR]
The 2nd range is entered like this:
^A4^D170[CR]Range2LowThreshold[CR]
^A5^D170[CR]Range2Target[CR]
^A6^D170[CR]Range2UpperThreshold[CR]
The 3rd range is entered like this:
^A7^D170[CR]Range3LowThreshold[CR]
^A8^D170[CR]Range3Target[CR]
^A9^D170[CR]Range3UpperThreshold[CR]]
Value1 is the lower boundary, value3 is the upper boundary, and value2 is the
blsy value for this range. Up to 9 values can be entered for a total of 3 ranges.
All values are non volatile and are stored with the other non volatile
parameters. Like the table, if the measured blsy doesn't fall into any of the
ranges the value won't change and will be used as is.
To see all of the table and user values enter
^A0^D170 [CR]
Using one of these smart autosize modes gives the user single dot accuracy in
using Boca autosize to find blsy.
6 Reserved
5-14
203 dpi
norm hi
406 457
508 558
609 634
660 685
711 761
812 863
914 964
1015 1066
1117 1129
1142 1180
1218 1269
1320 1370
1421 1827
2233 2300
300 dpi
low norm
525 600 675
676 750 825
826 900 938
939 975 1013
1014 1050 1125
1126 1200 1275
1276 1350 1425
1426 1500 1575
1576 1650 1669
1670 1688 1744
1745 1800 1875
1876 1950 2025
2026 2100 2700
2701 3300 3400
238B Operator's Manual - 880053-0101
Chapter 5
hi
