Chapter 5
^A ^D COMMAND
XX 43 Load Label Height in dots (LSY): The ^Axx specifies the value.
XX 44 Load the Web Size in dots (WEB): The ^Axx specifies the value.
XX 45 Load the Gap Size in dots (GAP): The ^Axx specifies the value.
XX 46 Load Print Speed: The ^Axx specifies the value.
XX 47 Load the Label Control Byte (LCB): The ^Axx specifies the value.
XX 48 Load the Number of Steps to Activate Gap Detector (AGD): The ^Axx
specifies the value in Dot Rows.
XX 49 Load the Number of Steps Past Gap (SPG): The ^Axx specifies the value
in Dot Rows.
XX 50 Load X Direction Offset (OFX): The ^Axx specifies the value.
XX 51 Load Y Direction Offset (OFY): The ^Axx specifies the value.
5.5.1 Serial Number Commands
The following commands, ^D80 through ^D89, are used for the serial number function
commands of the printer. The printer can increment or decrement any single serial number
on the label by any amount. If the format contains more than one serial number, then all
serial number fields can only increment or decrement by a value of one. Single and Multiple
serial number commands cannot be used on the same format. Please note that the ^D57
command clears most of the serial number commands. Therefore, all serial number
commands should be placed after the ^D56 command or just prior to the ^D3 command.
Refer to Section 5.4.1 for additional information regarding the use of the ^D75 command
and the serial number functions.
The following two commands are valid for both single and multiple serial number functions:
^A ^D COMMAND
80 Clears Commands 86, 88, 89.
81 Disable Serial Number Function: This command disables both single and
multiple serial number functions.
The next three commands deal with the single serial number functions:
XX 84 Load Text String Number to Increment/Decrement: Instructs the printer
which text string number to increment or decrement. The ^Axx value
determines which of the text strings will be used for incrementing or
decrementing.
XX 85 Load Increment/Decrement Step Value: The single serial number functions
increment or decrement by this value. ^Axx is the amount of increment or
decrement. Fields that instructs the printer to decrement beyond 0 will be set
to 0.
