TCI VALUE
24
25
26
28*
29*
32*
33*
35
36
37
38
40
41
42
43
44
46
47
48
49
50
51*
52
53
* Human Readable - Refer to Chapter 8
4.6.6 CGN (Character Generator Number)
The CGN parameter is a numeric entry that determines the representation and size of
embedded font and bar codes as well as the memory location of graphic images that have
been selected by the TCI parameter.
4.6.6.1 Standard Fonts
The Model 238 printers provide Helvetica style fonts that may be selected using the CGN
when text is selected by the appropriate TCI value.
CGN
VALUE
1
2
3
4
4-12
TCI DESCRIPTION
MSI 1 Symbol (Modified Plessey)
MSI 2 Symbol (Modified Plessey)
MSI 3 Symbol (Modified Plessey)
Text with MSI Checksum Added – Type 1
Text with MSI Checksum Added – Type 2
Text with UPC-A Checksum and Extended Bars Added
Text with UPC-A with Extended Bars Added
GS1 Databar Barcode
Postnet Symbol (Zip+4)
Postnet Symbol (Zip+6)
MaxiCode Symbol
Code 128 Symbol (Automatic Compression)
Code 128 Symbol (Full Implementation)
Codabar Symbol
Code 93 Symbol
AS-10 Symbol
PDF-417 Symbol
Data matrix
Intelligent Mail Barcode
Planet Code
UCC/EAN 128 Symbol
Text with EAN 128 Information
Aztec
QR Code
Table 4-4
POINT
SIZE
6
8
10
12

TCI Values

FONT TYPE
Swiss™721 Bold
Swiss™721 Normal
Swiss™721 Normal
Swiss™721 Normal
