Aztec Minimum Error Correction; Aztec Modes - Microcom 238B Operator's Manual

Bar Codes
Minimum Error Correction- 0
This parameter is used to set the Minimum Error Correction level. This parameter must be
set to 0 for Auto if a non-Auto is selected for the size parameter.
Mode - 0
This parameter is used to set the mode to be used in generating the Aztec barcode. A
value of 0 generates a standard Aztec while a setting of 2 would use the GS1 specification.
Please note that if the GS1 is used, the application identifiers should be entered with
brackets, Example: [21]123
8.1.26 QR Code, TCI 53
QR Code is a high density 2 dimensional barcode that can encode up to 7089 characters.
QR Code was designed for high-speed component scanning
The D194 command is used to receive and process the QR Code barcode with the
elements discussed below.
Once the QR Code barcode data is entered and processed, the barcode image may be
placed using the normal format field by using a TCI of 53.
8-28
Minimum Err Correction
0
1
2
3
4
Table 8-11

Aztec Minimum Error Correction

Modes
0
1
2
Table 8-12
Auto
10% + 3 words
23% + 3 words
36% + 3 words
50% + 3 words
Standard
Reserved
GS1*

Aztec Modes

238B Operator's Manual - 880053-0101
Chapter 8
