10 CBL_PWR_N
J1207
Pin No. Pin Name
1 GND
2 DBG_RXD
3 DBG_TXD
J1203
Pin No. Pin Name
1 3V3
2 NC
3 1V8
J0104
Pin No. Pin Name
1 SPI_CS
2 SPI_MOSI
J0105
Pin No. Pin Name
1 SPI_MISO
2 SPI_CLK
J0102
Pin No. Pin Name
1 VDD_EXT
2 USB_BOOT
5G-REDCAP_EVB_User_Guide
46
133
Module Pin No.
0–12, 23, 26, 33, 35,
38, 40, 50, 52, 54,
56–60, 62, 78, 109,
115, 125, 126, 135,
137, 140, 141, 143,
149, 151, 163, 169–204
13
14
Module Pin No.
NA
NA
NA
Module Pin No.
41
42
Module Pin No.
43
44
Module Pin No.
7
22
Connected directly to CBL_PWR_N of the
module
Description
Ground
Connected directly to DBG_RXD of the module
Connected directly to DBG_TXD of the module
Description
3.3 V power
NC
1.8 V power
Description
Connected directly to SPI_CS of the module
Connected directly to SPI_MOSI of the module
Description
Connected directly to SPI_MISO of the module
Connected directly to SPI_CLK of the module
Description
Connected directly to VDD_EXT of the module
Connected directly to USB_BOOT of the module
