Quectel 5G Module Series User Manual page 39

Table 20: Pin Definition of Test Points
J1204
Pin No. Pin Name
1 GND
2 PWRKEY
3 POWER_EN
4 RESET_N
5 RI
6 AP_READY
7 DCD
8 MAIN_RTS
9 MAIN_CTS
10 MAIN_DTR
J1202
Pin No. Pin Name
1 GND
2 WAKEUP_IN
3 0V9
4 W_DISABLE#
5 1V65
6 ADC0
7 3V
8 ADC1
9 VRTC
5G-REDCAP_EVB_User_Guide
46
Module Pin No.
0–12, 23, 26, 33, 35,
38, 40, 50, 52, 54,
56–60, 62, 78, 109,
115, 125, 126, 135,
137, 140, 141, 143,
149, 151, 163, 169–204
25
NA
24
68
NA
69
71
70
72
Module Pin No.
0–12, 23, 26, 33, 35,
38, 40, 50, 52, 54,
56–60, 62, 78, 109,
115, 125, 126, 135,
137, 140, 141, 143,
149, 151, 163, 169–204
1
NA
NA
NA
49
NA
48
NA
Description
Ground
Connected directly to PWRKEY of the module
DTR control module power
Connected directly to RESET_N of the module
Connected directly to MAIN_RI of the module
Application processor ready
Connected directly to MAIN_DCD of the module
Connected directly to MAIN_RTS of the module
Connected directly to MAIN_CTS of the module
Connected directly to MAIN_DTR of the module
Description
Ground
Connected directly to WAKEUP_IN of the
module
0.9 V power
Airplane mode control
1.65 V power
Connected directly to ADC0 of the module
3 V power
Connected directly to ADC1 of the module
NC
