3.8. Wi-Fi TE-A Interfaces
The Wi-Fi TE-A interfaces are designed to accommodate the Wi-Fi. The Wi-Fi TE-A interfaces support
SDIO or PCIe interface, and the QCA6174 TE-A (PCIe interface) is chosen by default. The proper TE-A is
connected to the EVB via BTB connectors. The interfaces allow you to test the Wi-Fi function of the
module or to develop applications with Wi-Fi function easily.
Table 15: Description of Wi-Fi TE-A Interfaces
RefDes.
J0301
J0302
5G-REDCAP_EVB_User_Guide
46
Description
Wi-Fi TE-A connectors
Wi-Fi TE-A
Figure 23: Connection Between Wi-Fi TE-A and EVB
J0301
J0302
5G Module Series
30 /
