3.2. Module TE-A Interface
Module TE-A interface is designed to accommodate the TE-A of applicable modules. The TE-A is
connected to the EVB via BTB connectors. The developer will be able to test the functionalities of the
module easily (insert as indicated by the arrow to prevent reverse insertion).
Table 4: Description of Module TE-A Interface
RefDes.
J0101
J0103
The following figure shows the connection between the module TE-A and the EVB.
Figure 8: Connection Between the Module TE-A and EVB
5G-REDCAP_EVB_User_Guide
46
Description
Module TE-A connector
J0103
Module TE-A
J0101
5G Module Series
19 /
