3.10. Antenna Interfaces
The EVB includes six antenna interfaces:
Table 17: Description of Antenna Interfaces
RefDes.
J1604
J1617
J1619
J1620
J1623
J1624
The following figure shows the assembly of these antenna interfaces.
5G-REDCAP_EVB_User_Guide
46
Description
Antenna connectors
J1617
J1623
J1619
Figure 26: Antenna Interfaces
J1624
J1620
J1604
5G Module Series
33 /
