  • Page 1 Quectel Wireless Solutions Hands-On Training 2018 © Quectel Wireless Solutions Co., Ltd. All rights reserved...
  • Page 2 EVBs Overview Tools Qnavigator Tests Guide Q&A @ Quectel Wireless Solutions | Page 2...
  • Page 3 GSM EVB & TE-A @ Quectel Wireless Solutions | Page 3...
  • Page 4 Q: Battery interface (Not used) R: Fixture hole for RF cable connector S: (U)SIM card interface T: Fixture holes for EVB poles U: Screw holes for fixing the module V: SD card interface @ Quectel Wireless Solutions | Page 4...
  • Page 5 GSM EVB – Interfaces Bottom Side D: Adapter interface L: Handset interface of audio channel 2 M: Handset interface of audio channel 1 V: SD card interface @ Quectel Wireless Solutions | Page 5...
  • Page 6 GSM EVB - Accessories @ Quectel Wireless Solutions | Page 6...
  • Page 7 UMTS&LTE EVB & TE-A @ Quectel Wireless Solutions | Page 7...
  • Page 8 UMTS&LTE EVB - Interfaces @ Quectel Wireless Solutions | Page 8...
  • Page 9 UMTS&LTE - Accessories @ Quectel Wireless Solutions | Page 9...
  • Page 10 Smart EVB & TE-A @ Quectel Wireless Solutions | Page 10...
  • Page 11 Smart EVB - Interfaces J702: Headset J905: GPIO S802: ENG_Download S804: Battery Charge J701: SPI S801: Power Supply Option S803: ON/OFF J801: Battery Connector S901: Power On Module J602: Micro USB J904: GPIO J601: JTAG @ Quectel Wireless Solutions | Page 11...
  • Page 12 Smart EVB - Accessories @ Quectel Wireless Solutions | Page 12...
  • Page 13 GNSS EVB @ Quectel Wireless Solutions | Page 13...
  • Page 14 EVBs Overview Tools Qnavigator Tests Guide Q&A @ Quectel Wireless Solutions | Page 14...
  • Page 15 Tools @ Quectel Wireless Solutions | Page 15...
  • Page 16 EVBs Overview Tools Qnavigator Tests Guide Q&A @ Quectel Wireless Solutions | Page 16...
  • Page 17 QNavigator Tests Guide Step 1: If the tool is installed on Windows 7 or Vista, please first set the Compatibility and then click Run this program as an administrator before using it. @ Quectel Wireless Solutions | Page 17...
  • Page 18 If it is the first time to use this software,the user guidance would pop up as below. You can also click ESC button on the keyboard to skip it. Step 2: Click the Next button to enter the next step. @ Quectel Wireless Solutions | Page 18...
  • Page 19 QNavigator Tests Guide Step 3: Choose the right module and Click the Next button to enter the next step. @ Quectel Wireless Solutions | Page 19...
  • Page 20 QNavigator Tests Guide Step 4: QNavigator Main Interface @ Quectel Wireless Solutions | Page 20...
  • Page 21 QNavigator Tests Guide Step 5: Toolbar @ Quectel Wireless Solutions | Page 21...
  • Page 22 QNavigator Tests Guide Step 6: UART Configuration @ Quectel Wireless Solutions | Page 22...
  • Page 23 QNavigator Tests Guide Step 7: a) Connect to module b) Check Module Info c) Check SIM Registration d) Check SIM Info @ Quectel Wireless Solutions | Page 23...
  • Page 24 QNavigator Tests Guide Step 8: SMS a) Insert Receiver number b) Type of message c) Message to be sent d) Send message e) Read Message @ Quectel Wireless Solutions | Page 24...
  • Page 25 QNavigator Tests Guide Step 9: Voice Call a) Number to call b) Input/Output mode c) Set Volume d) Side Tone Gain @ Quectel Wireless Solutions | Page 25...
  • Page 26 Step 10: TCP Connection a) Set APN data b) Set Server data c) Data to be sent to server d) Data to be received from server Note: Use server IP Address: 220.180.239.212 TCP PORT: 8009 @ Quectel Wireless Solutions | Page 26...
  • Page 27 Step 11: UDP Connection a) Set APN data b) Set Server data c) Data to be sent to server d) Data to be received from server Note: Use server IP Address: 220.180.239.212 UDP PORT: 8012 http://bit.ly/quectel-udp-server @ Quectel Wireless Solutions | Page 27...
  • Page 28 QNavigator Tests Guide Step 12: PPP a) Set APN Configuration b) Check Network Info @ Quectel Wireless Solutions | Page 28...
  • Page 29 QNavigator Tests Guide Step 13: QuecLocator a) Set APN Configuration b) Check Position @ Quectel Wireless Solutions | Page 29...
  • Page 30 QNavigator Tests Guide Step 14: GNSS a) Set NMEA Port b) Check Positioning data c) Detailed information about GNSS @ Quectel Wireless Solutions | Page 30...
  • Page 31 QNavigator Tests Guide Step 15: General Commands @ Quectel Wireless Solutions | Page 31...
  • Page 32 EVBs Overview Tools Qnavigator Tests Guide Q&A @ Quectel Wireless Solutions | Page 32...
  • Page 33 Q&A @ Quectel Wireless Solutions | Page 33...
  • Page 34 Thank you! Floor, Hongye Building, No.1801 Hongmei Road, Xuhui District, Shanghai 200233, China Tel: +86-21-5108 6236 Fax: +86-21-5445 3668 Email: info@quectel.com Website: www.quectel.com © Quectel Wireless Solutions Co., Ltd. All rights reserved...
