Transistor Output Units
4-4-3

GT1-OD16MX Transistor Output Unit with Connector (NPN)

Output Specifications
Components
I/O Unit Interface
Communications Connector 1
(on the Communications Unit side)
Internal Circuits
Item
Number of outputs
Current per common
TS Indicator (Refer to page 200.)
Output Indicators
Display the status of the outputs.
Lit when an output is ON.
DIN Track Mounting Hook
Terminal Block
16 points
2 A max.
I/O Unit Interface
Communications Connector 2
(on the terminator Side)
Digital Output Connectors
(made by MOLEX)
Connect to output devices,
such as relays and solenoids.
Low voltage
Drive power
supply
Drive power
supply
Photo-
coupler
Drive power
supply
Photo-
coupler
Section 4-4
Specifications
V (Terminal block)
G (Terminal block)
V (Connector)
Output 0
(Connector)
G (Connector)
V (Connector)
Output 1
(Connector)
G (Connector)
71
