Transistor Input Units
Internal Circuits
Terminal Arrangement
Connector Pin Arrangement
Wiring
56
Photo-
coupler
Photo-
coupler
Pin
A12 A11 A10 A9
number
NC
Function
Pin
B12 B11 B10 B9
number
NC
Function
Attach a FUJITSU connector to the Transistor Input Unit and connect it to the
external devices.
Applicable Connectors
Three types of connectors can be attached to the cable depending on the
assembly method. When creating your own cables, use one of the following
connectors.
Manufacturer
FUJITSU
FCN361J024-AU
FCN363J024-AU
FCN367J024-AU/F
A8
A7
A6
G
NC NC
IN
IN
IN
07
06
05
B8
B7
B6
NC NC
G
IN
IN
IN
15
14
13
Model number
Section 4-3
V (Terminal block)
G (Terminal block)
Input (IN00 to IN07)
Row A connector
G (Connector)
Input (IN08 to IN15)
Row B connector
A5
A4
A3
A2
A1
IN
IN
IN
IN
IN
04
03
02
01
00
B5
B4
B3
B2
B1
IN
IN
IN
IN
IN
12
11
10
09
08
Remarks
Soldered
Crimp
Pressure-welded
