Analog Output Units
Dimensions
5-2-2
GT1-DA04MX
130
Note The vertical center of the Unit is 4.9 mm lower than the center of the DIN
track. The Unit therefore extends downward 41.4 mm (including the mounting
hook) from the DIN track center.
General Specifications
Item
I/O connections
Number of outputs
Internal
Voltage range
power sup-
Current consump-
ply
tion in Unit (inrush
current)
Current consumption
(I/O Unit interface)
Noise immunity
Vibration resistance
Shock resistance
Ambient temperature
Ambient humidity
Operating atmosphere
Storage temperature
Safety standards
EMC directives
Mounting
Weight
Approx. 80
Specification
Connectors (made by MOLEX)
4 outputs (allocated four words in the Master Unit)
20.4 to 26.4 VDC (24 VDC
100 mA max.
(inrush current 30 A max.)
50 mA max.
2000 V
(IEC61000-4-4 via fast transient noise simulator)
10 to 150 Hz, 1.0-mm double amplitude or 70 m/s
2
200 m/s
–10 C to 55 C
25% to 85% (with no condensation)
No corrosive gases
–25 C to 65 C
UL508, CSA22.2
EN50081-2, EN50082-2
DIN 35-mm track
Approx. 180 g
Section 5-2
(Unit: mm)
+10%
/
)
–15%
2
