Transistor Output Units
Dimensions
4-4-4

GT1-OD16MX-1 Transistor Output Unit with Connector (PNP)

Output Specifications
Components
I/O Unit Interface
Communications Connector 1
(on the Communications Unit side)
110
Note The vertical center of the Unit is 4.9 mm lower than the center of the DIN
track. The Unit therefore extends downward 41.4 mm (including the mounting
hook) from the DIN track center.
Item
Number of outputs
Current per common
(Refer to page 200.)
TS Indicator
Output Indicators
Display the status of the outputs.
Lit when an output is ON.
Terminal Block
16 points
2 A max.
DIN Track Mounting Hook
Approx. 70
60
(Unit: mm)
Specifications
I/O Unit Interface
Communications Connector 2
(on the terminator side)
Digital Output Connector
(made by MOLEX)
Connects to the output devices,
such as relays and solenoids.
Section 4-4
73
