Omron DEVICENET#05-2003 Operation Manual page 218

Slave Device Profiles
Connection Object (0x05)
Object class Attribute
Service
Max. number of active connections
Item
Object instance 1 Instance type
Production trigger
Transport type
Transport class
Item
Object instance 1 Attribute
Item
Object instance 1 Service
Item
Object instance 2 Instance type
Production trigger
Transport type
Transport class
Section
Explicit Message
Cyclic
Server
3
ID content
1 State
2 Instance type
3 Transport class trigger
4 Produced connection ID
5 Consumed connection ID
6 Initial comm. characteristics
7 Produced connection size
8 Consumed connection size
9 Expected packet rate
12 Watchdog time-out action
13 Produced connection path length
14 Produced connection path
15 Consumed connection path length
16 Consumed connection path
17 Production inhibit time
DeviceNet service
05 Reset
0E Get_Attribute_Single
10 Set_Attribute_Single
Section
Polled I/O
Cyclic
Server
2
Not supported
Not supported
1
Information
Get
(read)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
No
Information
Appendix A
Max. number of instances
1
---
---
---
Set Value
(write)
No ---
No 0000 Hex
No 8300 Hex
No ---
No ---
No 2100 Hex
No FF00 Hex
No FF00 Hex
Yes ---
No 0100 Hex
No 0000 Hex
No ---
No 0000 Hex
No ---
No 0000 Hex
Parameter option
Max. number of instances
1
---
---
---
211
