Executing Multiple Functions with a Single Operation
8. Click the Add Button to add the new action item.
9. Click the Switch Screen Button and select Switch Screen from the dis-
played menu.
10. Set Specified Screen for the switch method, and 0100 Screen for the
screen selection.
When the Multifunction Object is pressed on the NS-series PT, the functions
that have been set will be executed in order.
Section 4-16
1. Click the Add Button.
2. Click the Write Button and
select Write Word.
3. Make the following settings:
●
Write Address: SERIAL A:DM0
●
Action: Set Value
Set Value: 123
●
1. Click the Add Button.
2. Click the Switch Screen
Button, and select Switch
Screen.
3. Make the following settings:
●
Switch Method: Specified Screen
●
Select Screen: 0100 Screen
71
