Menu Commands
PT Menu
Command
Transfer
Quick transfer Compares project data with data in the PT and
(Computer →
transfers only refreshed data to the PT.
PT)
Transfer (Com- Transfers all project data to the PT.
puter → PT)
Transfer (PT →
Uploads the project data stored in the PT to
Computer) the computer.
Transfer Setting Sets the communications path to be used in
the transfer.
Transfer Pro- Starts the tool for transferring project data cre-
gram ated on the CX-Designer to the PT or receive
project data from the PT to the CX-Designer.
System Setting Sets the PT operating parameters. (This is the
same as double-clicking System Setting on
the project workspace System Tab Page.)
Project Properties Sets the project properties. (This is the same
as double-clicking Project Properties on the
project workspace System Tab Page.)
Communication Registers hosts and sets communications
Setting conditions. (This is the same as double-click-
ing Communication Setting on the project
workspace System Tab Page.)
Alarm/Event Setting Registers and corrects alarms and events.
(This is the same as double-clicking Alarm/
Event Setting on the project workspace Com-
mon Setting Tab Page.)
Data Log Setting Registers and corrects the data log function.
(This is the same as double-clicking Data Log
Setting on the project workspace Common
Setting Tab Page.)
Broken-line Graph Registers and corrects broken-line graph
Group Setting groups. (This is the same as double-clicking
Broken-line Graph Group Setting on the
project workspace Common Setting Tab
Page.)
Data Block Setting Registers and corrects data blocks.
(This is the same as double-clicking Data
Block Setting on the project workspace Com-
mon Setting Tab Page.)
Document Table Used to register or correct document files dis-
Setting played for document display objects. Used
only with NS-Runtime.
String Table Setting Used to register or correct character strings in
character tables. (This is the same as double-
clicking String Table Setting on the project
workspace Common Setting Tab Page.)
Function
Section 3-2
Shortcut keys
Ctrl+Q
Ctrl+B
Ctrl+Shift+B
Ctrl+Alt+B
Ctrl+I
---
---
---
---
---
---
---
---
