Searching for Embedded Macros

Note
4-9

Searching for Embedded Macros

1,2,3...
60
2. Set the addresses and search range and click the Go Button to display the
number of times the addresses are used.
Displays the addresses.
3. Select an address and click the Find Reference Object Button to display
a list of functional objects using that address in the Output Window. Select
a functional object in the Output Window to automatically select that object
on the screen.
Objects selected in the Output Window are selected on the screen.
Searches can be made for the addresses used in a project or in a screen and
the results displayed in a list. Select Find - Address Cross Reference.
Embedded macros can be found and displayed in the Output Window.
Objects selected in the Output Window are automatically selected, so macro
details can be checked on the Property List.
Procedure
1. Select Find - Macro Cross Reference.
2. Specify the search range in the displayed Search Embedded Macro Dialog
Box and execute the search.
3. A list of macro locations will be displayed in the Output Window.
Section 4-9
Sets the start
address for the
search range.
Sets the search
range.
Displays the
number of times
each address is
used. (Unused
addresses are
displayed in gray.)
