Installing The Cx-Designer - Omron CX-DESIGNER V2.1 - 07-2007 User Manual

Installing the CX-Designer

Using CX-Designer with
Windows Vista
2-2 Installing the CX-Designer
Note
1,2,3...
The following restrictions apply when using CX-Designer with Windows Vista.
Item
Fonts
Memory Card Transfer
Support Software
Install the CX-Designer in the hard disk.
To install the CX-Designer, execute the installation program provided.
For details on procedures for installing the CX-Designer from CX-One FA Inte-
grated Tool Package, refer to the CX-One Ver. 2.1 Setup Manual provided with
CX-One.
Cat. No. Model
W463 CXONE-AL@@C-
EV2/AL@@D-EV2
If the CX-Designer was previously installed from the CX-One and it's neces-
sary to install it from the individual CX-Designer CD-ROM, always uninstall
the CX-Designer using the following procedure before installing it from its indi-
vidual CD-ROM. The CX-Designer will not operate properly if it is installed
without first uninstalling it.
1. Insert the CX-One installation disk 1 into the CD-ROM drive.
2. Select the Modify Option to enable modifying the Support Software that is
installed.
3. In the Select Features Dialog Box, clear the selection of only the CX-De-
signer. Do not change any other selections.
4. Continue by following the instructions in the dialog boxes to modify the in-
stallation and uninstall CX-Designer.
5. Once the CX-Designer uninstallation process has been completed, place
the individual CD-ROM disk for the CX-Designer into the CD-ROM drive
and install the CX-Designer. (See note.)
Note If the version of the CX-Server bundled on the individual CX-De-
signer CD-ROM is lower than the version of the CX-Server bundled
with the CX-One, install only the CX-Designer and NOT the CX-
Server. If a version of CX-Server that is lower than the version with
the CX-One is installed, the CX-One will not operate properly.
The main buttons that are displayed during installation are as follows:
Confirms the settings in the window displayed and moves to the next
window.
Cancels the settings in the window displayed and returns to the previ-
ous window.
Contents
When project data created outside of Windows Vista is
saved in Windows Vista, characters using fonts that are
different in Windows Vista will be changed.
Similarly, characters in project data using fonts added or
changed in Windows Vista will be changed when saved
outside of Windows Vista.
Two-bytes characters used in file names and folder
names on the Memory Card will not be displayed nor-
mally.
Manual name
CX-One Ver. 2.1 Installation and overview of CX-
Setup Manual One FA Integrated Tool Package.
Section 2-2
Contents
13
