Starting and Exiting CX-Designer

3-1 Starting and Exiting CX-Designer
3-1-1 Startup Method
Note
3-1-2 Exiting CX-Designer
26
This section describes how to start and exit the CX-Designer.
To start the CX-Designer, click the Windows Start Button, and then select
Programs - OMRON - CX-One - CX-Designer - CX-Designer Ver. @ (The
items displayed may vary according to the program folder specified during
installation). Alternatively, right-click the NS-series PT in the Network Configu-
ration Window of CX-Integrator, and select Start Special Application - Start
Only.
When the CX-Designer startup is completed, the Main Window will be dis-
played, as follows:
(1) More than one copy of the CX-Designer application can be run at the
same time.
(2) To start CX-Designer, log in as the administrator when using a personal
computer running Windows NT, 2000, XP, or Vista.
Use one of the following operations to exit the CX-Designer.
• Select Exit from the File Menu.
• Click the Close Button
• Double-click the CX-Designer icon at the top left of the Main Window.
• Click the CX-Designer icon at the top left of the Main Window and select
Close from the Control Menu Box.
• Press the Alt + F4 Keys.
If the project data that is open has not been saved, a confirmation message
will be displayed.
When the CX-Designer is exited, the system will return to the Windows dis-
play.
at the top right of the Main Window.
Section 3-1
