User Interface
Property List
Screen Creation Window
Status bar
36
Property Lists display the property settings for the functional object selected
on the screen. Settings can be checked and changed without opening a Prop-
erty Setting Dialog Box.
Changes to properties made on the Property List are immediately reflected on
the screen, which enables changes to be checked during screen creation.
Property Lists can be displayed and hidden by selecting View - Window -
Property List.
Enables display
and settings of
properties of
the selected
object without
opening a
property dialog
box.
■ Global Replace
More than one object can be selected and the common settings for those
objects can be changed in one operation.
The following example shows a global change of the object color.
The two objects on the
screen for which the color is
to be changed are selected
and Color 1 is changed.
Screens displayed on the PTs can be created using functional and fixed
objects.
The Status Bar can be displayed and hidden by selecting View - Status Bar.
Describes the
function of the
toolbar icon or
Displays the current
menu item
coordinates of the
selected.
cursor.
Displays the
frame page
number currently
selected.
The color for the two
selected objects is changed
in the one operation.
Displays the
Displays the
system
switch label
version of
name currently
the project.
selected.
Displays the
Displays
upper left
the set PT
coordinates of the
model.
object currently
selected.
Section 3-3
Displays the
key status.
