Listing and Editing Functional Object Properties
1,2,3...
4-5-1

Setting Consecutive Addresses

1,2,3...
4-5-2

Copying the Same Setting to More Than One Cell

1,2,3...
56
Procedure
1. Select Edit - Edit Properties.
2. The functional objects on the screen and their properties will be displayed.
Entries made to each item will be reflected as changes in the functional ob-
ject.
The display can be
limited to functional
objects selected from
the list.
Addresses can be changed to make the address consecutive.
1. Select the cell for the set address and move the mouse to the bottom-right
of the cell. When the cursor changes to a + cursor, drag the cursor down
or up.
2. The addresses will change to descending order when the cursor is
dragged down, and to ascending order when dragged up.
Each setting can be copied to other cells for items of the same type.
1. Select and copy the desired cell.
Section 4-5
Click the Display Item Setting
Button to change property
settings displayed in the Edit
Properties Window.
