Listing and Editing Functional Object Properties

Note
4-4-1

Globally Replacing Settings for More Than One Object

1,2,3...
Note
4-5

Listing and Editing Functional Object Properties

The Property Settings Dialog Box for an object can still be displayed by dou-
ble-clicking the object.
More than one item can be selected and settings common to all items can be
changed. The changed settings will be reflected in all selected objects.
Procedure
1. Select all the objects for which settings are to be changed.
2. Change the setting items common to all selected objects on the Property
List.
3. The change will be reflected in all objects.
Items not common to all selected objects cannot be changed.
Properties of objects on the screen can be displayed in table format and the
settings changed.
Settings for more than one object can be changed at the same time and con-
secutive addresses can be automatically set, making editing more efficient.
The Property List is used
to display and set the
properties for the
selected object.
Changes to properties
are immediately reflected
on the screen, which
enables changes to be
checked during screen
creation.
The setting common
to the selected
objects, Color 1, will
be changed.
All selected
objects change
to the same
color.
Section 4-5
55
