User Interface
Objects can be easily registered and reused, using the drag-and-drop function.
Object List Window
42
Reuse
The Object List Window lists the functional objects located in Screen Creation
Window.
Any object can be selected and the display on the Screen Creation Window
can be restricted to a specified type of functional object from the Select Object
Window.
Selecting and displaying objects by type enables easy editing of objects hid-
den under other objects. Normal screen editing is also possible in this mode.
The Select Object Window can be displayed and hidden by selecting View -
Window - Object List.
Screen Creation Window
Label objects that were
hidden underneath
Register
Section 3-3
Library Window
Select Object Screen
Lists objects on the screen.
Select only Label to display
labels that were hidden under
other objects. Labels can also
be edited in this mode.
