3. Instructions

+C/+CL

Instruction
SIGNED BINARY ADD WITH
CARRY
DOUBLE SIGNED BINARY
ADD WITH CARRY
Symbol
Applicable Program Areas
Function block
Area
definitions
Usage OK
Operands
Operand
+C: Augend word
Au
+CL: First augend word
+C: Addend word
Ad
+CL: First addend word
+C: Result word
R
+CL: First result word
Operand Specifications
Area
CIO WR HR
Au, Ad
+C OK OK OK
R
Au, Ad
+CL OK OK OK
R
352
Mnemonic Variations
+C @+C
+CL @+CL
+C
+C(402)
Au
Au: Augend word
Ad Ad: Addend word
R R: Result word
Block program areas Step program areas
OK OK
Description
Word addresses
AR T C DM EM
OK OK OK OK OK
OK OK OK OK OK
Function
code
Adds 4-digit (single-word) hexadecimal data
402
and/or constants with the Carry Flag (CY).
Adds 8-digit (double-word) hexadecimal data
403
and/or constants with the Carry Flag (CY).
Subroutines Interrupt tasks
OK
Data type
+C +CL
INT DINT
INT DINT
INT DINT
Indirect
DM/EM Registers
Con-
addresses
stants
@DM *DM
DR IR
@EM *EM
OK
OK OK OK ---
---
OK
OK OK --- ---
---
CS/CJ/NSJ Series Instructions Reference Manual (W474)
Function
+CL
+CL(403)
Au Au: 1st augend word
Ad: 1st addend word
Ad
R R: 1st result word
SFC action or
transition programs
OK OK
Size
+C +CL
1 2
1 2
1 2
Pulse
TK CF
bits
Indirect
using IR
OK --- --- ---
OK --- --- ---
TR
bits
---
---
