3. Instructions

MOVR/MOVRW

Instruction
MOVE TO REGISTER
MOVE TIMER/COUNTER PV
TO REGISTER
Symbol
Applicable Program Areas
MOVR
Function block
Area
definitions
Usage OK
MOVRW
Function block
Area
definitions
Usage Not allowed
Operands
Operand
MOVR: Source (desired word or bit)
S
MOVRW: Source (desired TC number)
D Destination
Operand Specifications
Word addresses
Area
CIO WR HR
S OK OK OK
MOVR
D --- --- ---
S
MOVRW --- --- ---
D
Flags
Name
Error Flag
Equals Flag
Negative Flag
Note In CS1D CPU Units for Duplex Systems, CS1 CPU Units, and CJ1 CPU Units, these are turned OFF.
304
Mnemonic Variations
MOVR @MOVR
MOVRW @MOVRW
MOVR
MOVR(560)
S S: Source
(desired word or bit)
D
D: Destination
(Index Register)
Block program areas Step program areas
OK OK
Block program areas Step program areas
OK OK
Description
AR T C DM EM
OK OK OK OK OK
--- --- --- --- ---
OK OK
--- --- ---
--- ---
Label
ER Unchanged (See note.)
= Unchanged (See note.)
N Unchanged (See note.)
Function
code
Sets the PLC memory address of the specified
560 word, bit, or timer/counter Completion Flag in the
specified Index Register.
Sets the PLC memory address of the specified
561 timer or counter's PV in the specified Index Regis-
ter.
Subroutines
OK
Subroutines
OK
Data type
MOVR MOVRW
BOOL
WORD WORD
Indirect DM/EM
Registers
addresses
Con-
stants
@DM *DM
DR
@EM *EM
--- --- --- ---
--- --- --- ---
Operation
CS/CJ/NSJ Series Instructions Reference Manual (W474)
Function
MOVRW
MOVRW(561)
S: Source
S
(desired TC number)
D D: Destination
(Index Register)
SFC action or
Interrupt tasks
transition programs
OK OK
SFC action or
Interrupt tasks
transition programs
OK Not allowed
Size
UINT 1
2
Flags
Pulse
bits
Indirect
IR TK CF
using IR
--- OK
--- --- ---
OK ---
---
--- --- --- ---
OK
TR
bits
---
---
