Command Lists; Fins Commands - Omron CJ - REFERENCE MANUAL 07-2009 Reference Manual

Command Lists

5-1 Command Lists
5-1-1

FINS Commands

Type Command
MR
I/O memory area 01
access
01
01
01
01
Parameter area 02
access
02
02
Program area 03
access
03
03
Operating mode 04
changes
04
Machine configura- 05
tion reading
05
Status reading 06
06
Time data access 07
07
Message display 09
Access rights 0C
0C
0C
Error log 21
21
21
150
The following table lists the FINS commands.
code
SR
01 MEMORY AREA READ
02 MEMORY AREA WRITE (See note.)
03 MEMORY AREA FILL (See note.)
04 MULTIPLE MEMORY AREA READ
05 MEMORY AREA TRANSFER (See
note.)
01 PARAMETER AREA READ
02 PARAMETER AREA WRITE (See note.) Writes the contents of consecutive
03 PARAMETER AREA FILL (CLEAR)
(See note.)
06 PROGRAM AREA READ
07 PROGRAM AREA WRITE (See note.)
08 PROGRAM AREA CLEAR (See note.)
01 RUN (See note.)
02 STOP (See note.)
01 CPU UNIT DATA READ
02 CONNECTION DATA READ
01 CPU UNIT STATUS READ
20 CYCLE TIME READ
01 CLOCK READ
02 CLOCK WRITE (See note.)
20 MESSAGE READ/CLEAR
01 ACCESS RIGHT ACQUIRE (See note.) Acquires the access right as long as no
02 ACCESS RIGHT FORCED ACQUIRE
03 ACCESS RIGHT RELEASE
01 ERROR CLEAR (See note.)
02 ERROR LOG READ
03 ERROR LOG CLEAR (See note.)
Name
Reads the contents of consecutive I/O
memory area words.
Writes the contents of consecutive I/O
memory area words.
Writes the same data to the specified
range of I/O memory area words.
Reads the contents of specified non-
consecutive I/O memory area words.
Copies the contents of consecutive I/O
memory area words to another I/O
memory area.
Reads the contents of consecutive
parameter area words.
parameter area words.
Writes the same data to the specified
range of parameter area words.
Reads the UM (User Memory) area.
Writes to the UM (User Memory) area.
Clears the UM (User Memory) area.
Changes the CPU Unit's operating
mode to RUN or MONITOR.
Changes the CPU Unit's operating
mode to PROGRAM.
Reads CPU Unit data.
Reads the model numbers of the device
corresponding to addresses.
Reads the status of the CPU Unit.
Reads the maximum, minimum, and
average cycle time.
Reads the present year, month, date,
minute, second, and day of the week.
Changes the present year, month, date,
minute, second, or day of the week.
Reads and clears messages, and reads
FAL/FALS messages.
other device holds it.
Acquires the access right even if
another device already holds it.
Releases the access right that has been
acquired.
Clears errors or error messages.
Reads the error log.
Clears the error log pointer.
Section 5-1
Function
