Pulsing Mode; Output Options; Off On Low Battery; Guest Control - Bosch Solution 6000-IP Installation Manual

Total Time Hour
60 Minutes 001
60 Minutes 000
Table 19: Example - Output One Shot Timer

Pulsing Mode

The time base is the unit of time that the output will pulse
on and off. If the time base is programmed for 60 seconds,
the output will pulse on for 60 seconds and then off for 60
seconds (repeat) until the output is reset.
Outputs > Properties >

Output Options

1

Off On Low Battery

2

Guest Control

3

Reserved

4

Monitor Overload

5

Monitor Device Fail

6

Alarm On Device Fail

7

Block If All On

8

Show Status On Keypad

1) Press [MENU] + [4] + [1] + [5] and select the output
you want to program from the list then press [OK].
Alternatively, you can directly enter the output
number then press [OK].
2) Use the up and down arrow keys to highlight the
option then press the [ON] key to enable or the
[OFF] key to disable.
 Off On Low Battery
Guest Control
Reserved
Press  OK ON OFF MENU
3) Repeat Step 2 until all options are programmed as
required, then press [OK] to save and exit or press
[MENU] to exit without saving.
Off On Low Battery
This option forces the control panel not to operate the
output when a low battery or missing battery condition
is in effect. Once the low battery condition restores, the
output will return to normal operation.
Bosch Security Systems 10/22 BLCC615I
Minute Seconds 10th Sec
000 000 000
060 000 000
 MENU 4-1-5
Solution 6000-IP

Guest Control
Guest control when enabled allows the output to be
controlled from the quick select menu on the keypad
which is a simple pull down menu. This allows you to
view and alter the state of the output without the need
of a PIN. To simply turn on or off guest control outputs,
press the [←] key.
Monitor Overload
Monitor Overload when selected will monitor the output
for an overload condition and display as well as report if
an overload condition occurs. The event will always be
logged regardless if enabled or not.
Monitor Device Fail
Monitor device fail when selected will monitor the
Y
output for a disconnection condition and display as well
N
as report when a disconnection occurs.
N
Alarm On Device Fail
Y
This option causes the panel to sound an alarm when
Y
the output device becomes missing (armed or disarmed
N
state).
N
Block If All On
N
This option prevents the output from turning on when
the corresponding area is turned All On. When the area
is off, Part On or Part 2 On, the output can again operate
when the output event occurs.
Show Status On Keypad
This option allows the keypad to display the output that
is currently active on the keypad.
Outputs > Properties >

Macro Group

Reserved
Installation Manual Output Programming

 MENU 4-1-6
8-13
