  • Page 1 Solution 6000-IP Security Systems Installation Guide Security System...
  • Page 2 Desig ned In Aust ra lia RoHS Bosch Security Systems Pty Ltd reserves the right to make changes to features and specifications at any time 9) This equipment shall not be set up to make without prior notification in the interest of ongoing automatic calls to the Telecom ‘111’...

  • Page 3: Table Of Contents

    GETTING STARTED WITH MYALARM .............................4-2 SERVICE MODE ..................................4-2 Turning Service Mode ON ......................................4-2 Turning Service Mode OFF ......................................4-2 DEFAULTING THE SYSTEM ..............................4-3 Hardware Default ..........................................4-3 Software Default ..........................................4-3 TRIGGERING A DURESS ALARM ............................4-3 Bosch Security Systems 10/22 BLCC615I...
  • Page 4 PIN Length ......................................5-10 PIN Retry Count..................................... 5-10 Installer PIN ......................................5-11 Access Route ......................................5-11 Access Options ...................................... 5-11 Access Granted ..........................................5-11 Access Denied ..........................................5-11 Egress Granted ..........................................5-11 Egress Denied..........................................5-11 Add Fingerprint ....................................5-12 Bosch Security Systems 10/22 BLCC615I...
  • Page 5 Open Close Route ....................................6-8 AREAS TIMERS ..................................6-8 Exit Time ........................................6-8 Entry Time 1 ......................................6-9 Entry Time 2 ......................................6-9 Part Entry Time ......................................6-9 Auto Arm Pre-Alert ....................................6-10 Senior Watch Time ....................................6-10 Bosch Security Systems 10/22 BLCC615I...
  • Page 6 Report Troubles ..........................................7-10 Report Bypass ..........................................7-10 Report Restores ..........................................7-10 Delay Reporting ..........................................7-10 Zone Options ......................................7-10 Lockout Siren ..........................................7-10 Silent Alarm .............................................7-10 Inverted Seal ...........................................7-10 Bypass Allowed ..........................................7-11 Sensor Watch ..........................................7-11 Armed In Part On ..........................................7-11 Bosch Security Systems 10/22 BLCC615I...
  • Page 7 Output Options ..................................... 8-13 Off On Low Battery ........................................8-13 Guest Control ..........................................8-13 Monitor Overload .........................................8-13 Monitor Device Fail ........................................8-13 Alarm On Device Fail ........................................8-13 Block If All On ..........................................8-13 Show Status On Keypad ......................................8-13 Macro Group ......................................8-13 Bosch Security Systems 10/22 BLCC615I...
  • Page 8 Account Prefix ..........................................9-9 Receiver Prefix ..........................................9-9 User Name/Password ..................................... 9-9 Use SIA Format ..........................................9-10 SIA With Text ...........................................9-10 32 Bit Checksum ..........................................9-10 IP RAS Allowed ..........................................9-11 IP RAS Only If Disarmed ......................................9-11 viii Bosch Security Systems 10/22 BLCC615I...
  • Page 9 Report Keypad Fire ........................................10-8 Audible Kpad Medical .........................................10-8 Report Kpad Medical ........................................10-8 Audible Kpad Panic ........................................10-8 Report Keypad Panic ........................................10-8 Door Assignment ....................................10-8 Lockout Time ......................................10-9 Wi-Fi Settings ......................................10-9 SSID Scan ............................................10-9 Bosch Security Systems 10/22 BLCC615I...
  • Page 10 Report IP Conflict ........................................10-16 Report Poll Fail ..........................................10-16 Report Module Missing ......................................10-16 SECTION 11 SYSTEM PROGRAMMING ........................11-1 SYSTEM COMMANDS ................................11-1 Panel Status ......................................11-1 System Trouble ...................................... 11-1 SYSTEM TROUBLE MESSAGES .............................11-2 Power Missing ..........................................11-2 Bosch Security Systems 10/22 BLCC615I...
  • Page 11 Display COMM+ O/Load ......................................11-9 Report COMM+ O/Load ......................................11-9 Display +12v O/Load ........................................11-9 Report +12v O/Load ........................................11-9 Display LAN O/Load ........................................11-9 Report LAN O/Load ........................................11-9 HORN SPEAKER OPTIONS ..............................11-9 Tone ......................................... 11-9 Speed ........................................11-10 Volume .........................................11-10 Siren Swinger ......................................11-10 Bosch Security Systems 10/22 BLCC615I...
  • Page 12 Unlocking a Door and Disarming Area 1 using a LAN Reader........................12-2 Unlock a Door and Arm/Disarm Area 1 using a LAN Reader ........................12-2 Door Auto Lock/Unlock By TimeZone ...................................12-3 SECTION 13 SPECIFICATIONS ............................13-1 SECTION 14 INDEX ..............................14-1 Bosch Security Systems 10/22 BLCC615I...

  • Page 13: Overview

    S E C TIO N 1 Overview F E AT U R E S O V E R V I E W Listed below are the main features of the Solution 6000-IP Zones Control Panel. The Solution 6000-IP control panel provides up to 144 ♦...
  • Page 14 Solution 6000-IP Installation Manual Overview   This page left intentionally blank Bosch Security Systems 10/22 BLCC615I...

  • Page 15: Installing The Hardware

    6kg to fix the cabinet against a sturdy surface using the of the enclosure before mounting it to the wall, or from mounting holes provided. the front of the enclosure after it has been mounted. Both methods should be performed using your finger tips to Bosch Security Systems 10/22 BLCC615I...

  • Page 16: Installing Panels And Modules

    All compatible add on modules will mount on these spaces. See below for list if modules which can be added to the control panel. Module Space Occupied Solution 6000-IP Control Panel 2 Module Spaces CM704B Zone Expander 1 Module Space CM705B Universal Expander...
  • Page 17 = Earth Stud - 4mm Figure 6: MW730B - Large Enclosure Details The following examples show the MW730B - Large enclosure configured using 6 small modules and 1 large module. Figure 5: MW720B Configuration Examples Bosch Security Systems 10/22 BLCC615I...

  • Page 18: Connecting Power To The Panel

    If using a 3 wire Adaptor, then the earth wire should also be terminated onto the terminal block. Always check the orientation of the terminal block with the PCB markings before connecting it to the PCB. Bosch Security Systems 10/22 BLCC615I...

  • Page 19: Panel Led Indicators

    [OFF] key for two seconds after you enter your PIN. The [OK] key allows you to save any changes and exit the command. Bosch Security Systems 10/22 BLCC615I...

  • Page 20: Status Icons / Led's

    Table 6: Keypad Tones Area is off. Green Flashing Area not ready to turn on Red & Installer programming mode is Green Flashing active. The WiFi enabled keypad or module has successfully connected to your local WiFi network. Bosch Security Systems 10/22 BLCC615I...

  • Page 21: Keypad & Readers Setup

    D I P S W I TC H A D D R E S S S E L E C T Figure 10: Keypad DIP Switch Address Settings DIP Switch Address Settings Table 8: Rotary Switch Address Settings Keypad/Reader N Figure 11: Rotary Swich Address Settings Table 7: DIP Switch Address Settings Bosch Security Systems 10/22 BLCC615I...

  • Page 22: Eol Resistor Colour Code

    EOL Resistor Colour Codes Because of variations in the colours used to mark resistors it is recommended that you use a multimeter to verify the value of resistors rather than rely on the colour code. Bosch Security Systems 10/22 BLCC615I...

  • Page 23: Wiring Diagrams

    ALARM (3K3 EOL) ZN 2 Figure 16: N/C Zone With Tamper The Above diagrams display the zone wiring configurations using Normally-Closed Alarm Figure 20: N/O Zone With Tamper Note contacts and Normally-Open Alarm Contacts. When Bosch Security Systems 10/22 BLCC615I...

  • Page 24: Eol Resistor Colours And Values

    Zone 7 and 15 sensor loop input (+). Port Module etc) Common (-) for Zone 7 and 8 sensor loop. Table 10: Board Connector Descriptions ZN 8 Zone 8 and 16 sensor loop input (+). Table 11: Terminall Block Descriptions and Functions Bosch Security Systems 10/22 BLCC615I...

  • Page 25: Lan Overview

    CM720B Power Supply, do NOT termination point and is not internally connected. connect the EARTH wire from any 3 wire plug pack to the module’s EARTH input terminal, if you have installed a separate communication earth wire. Bosch Security Systems 10/22 BLCC615I...

  • Page 26: System Earthing

    LAN A and LAN B terminals. In smaller installations where no LAN modules have been installed there is no need to fit the termination resistor on the control panel. The LAN must be terminated correctly for proper operation. Note Bosch Security Systems 10/22 BLCC615I...
  • Page 27 Refer to Relay Output Documentation 24V D.C. 2Amp For Dialer & Status LED’s RF Receiver / Keyswitch 10-Pin Serial Input Connection Socket For Direct Link / Flash Programming etc. Zone Input Terminals Figure 24: Terminal Descriptions Bosch Security Systems 10/22 BLCC615I...
  • Page 28 RF DATA siren so the panel can monitor the ZONE 1 connection. ZONE 2 ZONE 3 ZONE 4 ZONE 5 Receiver ZONE 6 Connect +12V ZONE 7 Accessory Power ZONE 8 Figure 25: Wiring Diagram Bosch Security Systems 10/22 BLCC615I...

  • Page 29: Programming Overview

    [OFF] key. Off On Low Battery Show Overload  Report Overload Press OK ON OFF MENU  To save programming changes, press [OK] or press [MENU] to exit without saving. Bosch Security Systems 10/22 BLCC615I...

  • Page 30: Alpha Text

    Set Date And Time 4) Hold down [MENU] to exit. 01-Jan-2015 12:00 You must exit Service Mode to reactivate the system. Press OK to SAVE Service mode will automatically exit after 2 hours.  Note Bosch Security Systems 10/22 BLCC615I...

  • Page 31: Defaulting The System

    5 seconds to initiate F = Output 10 has a Fault (Overload) the programming session. See the board layout drawings T = Output 09 is Triggered (On) in Section 3 of this manual for the default switch location. Bosch Security Systems 10/22 BLCC615I...

  • Page 32: Testing The System

    Zn921 - 928 LAN Isolator 9 - 16 by holding down the Test / Mail key on the keypad. Zn931 - 938 LAN Power Supply 9 - 16 Zn951 - 958 Output Expander 9 - 16 Bosch Security Systems 10/22 BLCC615I...
  • Page 33 Solution 6000-IP Installation Manual Programming Overview   Zn971 - 978 Consoles 9 - 16 Table 14: Shortform Point ID Listing Bosch Security Systems 10/22 BLCC615I...

  • Page 34: Menu Reference Table

    Reporting 2-9-0 Area Watch 1-6-0 Access Route 2-9-1 User Test Interval 1-6-1 Access Options 2-9-2 Service Interval 2-9-3 Test Options Fingerprint 1-8-0 Add Fingerprint 1-8-1 Delete Fingerprint 1-8-2 Fingerprint Status Table 15: Menu Reference Table Bosch Security Systems 10/22 BLCC615I...
  • Page 35 Sensor Watch Time 5-7-3 RAS Lockout Time 5-7-5 IPRS Address 5-7-6 IPRS Port Comms Test UMI 5-9-0 Send Test Report 5-9-1 Test Report Time 5-9-2 Test Report Period 5-9-3 Test Report Options 5-9-4 Test Route Bosch Security Systems 10/22 BLCC615I...
  • Page 36 DNS Address 7-7-4 Installer Options 6-6-9 IP Options 7-7-5 Language 7-7-7 Site Name 7-7-8 Custom Text Line 1 7-7-9 Custom Text Line 2 System Testing UMI 7-9-0 Walk Test All Zones UMI 7-9-1 Battery Test Bosch Security Systems 10/22 BLCC615I...

  • Page 37: Basic System Operation

    PIN between 5:55pm and 6:00pm will delay the auto- on time by one hour and the auto-on pre-alert time will again commence at 6:55pm. Therefore the system will automatically turn All On at 7:00pm. Bosch Security Systems 10/22 BLCC615I...

  • Page 38: Remote Arming - Quick Arm

    [2] [5] [8] [0] + [8] [0] + [OK] or [ON]. 2) If your PIN is 2580, to send a duress report when the area is on, enter, [2] [5] [8] [0] + [8] [0] + [OFF]. 4-10 Bosch Security Systems 10/22 BLCC615I...

  • Page 39: Access Programming

    1) Pick a timezone access number between 2-16, lets again to release door. say 5. 2) Setup timezone 5 start time 8am, stop time 10pm, days MTWTF. 3) Assign each restricted user to timezone access 5. Bosch Security Systems 10/22 BLCC615I...

  • Page 40: User Default Table

    Ur3 User 3 Name Press OK or MENU  3) Verify the user name to be erased and press [OK]. To abort press [MENU]. To erase Ur1 John Smith press OK. Press OK or MENU Bosch Security Systems 10/22 BLCC615I...

  • Page 41: Change Own Pin

    The compromised PIN message will continue to be PIN changes their PIN to be different. displayed until one of the users that have the same PIN changes their PIN to be different. Bosch Security Systems 10/22 BLCC615I...

  • Page 42: Add Pin

    [OK]. The keypad will only list users that dont already have tokens assigned. Ur1 John Smith Ur2 Debbie Smith Ur3 User 3 Name Press OK or MENU  Bosch Security Systems 10/22 BLCC615I...

  • Page 43: Delete Token

    2) The keypad will display the current token ID of the user selected. Edit Token Ur1 0000000000 Press 0-9 OK to SAVE 3) Press [OK] to save and exit or press [MENU] to exit without saving. Bosch Security Systems 10/22 BLCC615I...

  • Page 44: Rf Keyfobs

    1) Enter [MENU] + [1] + [3] + [1] and use the up and down arrows to highlight the user in the list then press [OK]. The keypad will only list users that have an RF Keyfob assigned. Bosch Security Systems 10/22 BLCC615I...

  • Page 45: User Properties

    Press OK ON OFF MENU  3) Repeat Step 2 until you have assigned the user to all required areas, then press [OK] to save and exit, or press [MENU] to exit without saving. Bosch Security Systems 10/22 BLCC615I...

  • Page 46: User Options

    [OK] key. To prevent users from being able to force arm an area you will need to disable this option. Bosch Security Systems 10/22 BLCC615I...

  • Page 47: Timezone Access

    Door 2 Name Door 3 Name Press OK ON OFF MENU  3) Repeat Step 2 until all required door assignments are programmed, then press [OK] to save and exit or press [MENU] to exit without saving. Bosch Security Systems 10/22 BLCC615I...

  • Page 48: User Expire Date

    1) Enter [MENU] + [1] + [5] + [1]. The keypad will display the current PIN retry count. PIN Retry Count Press 0-9 OK to SAVE 5-10 Bosch Security Systems 10/22 BLCC615I...

  • Page 49: Installer Pin

    Denied' events using the destination set in MENU 1-6-0. 00 - Log Events Only Press  0-9 OK to SAVE 3) Press [OK] to save and exit or press [MENU] to exit without saving. 5-11 Bosch Security Systems 10/22 BLCC615I...

  • Page 50: Add Fingerprint

    [OK]. The system will only list users that have a fingerprint assigned. Ur1 John Smith Ur2 Debbie Smith Ur3 User 3 Name Press OK or MENU  5-12 Bosch Security Systems 10/22 BLCC615I...

  • Page 51: Area Programming

    Armed Partial - when the area has been turned Part On. assigned a home area and will automatically revert back to this area after 60 seconds. Armed Part 2 - when the area has been turned Part 2 On. Bosch Security Systems 10/22 BLCC615BI...

  • Page 52: Turn Area On/Off

    1) Enter [MENU] + [2] + [0] + [3] to disarm all areas. The chime tone will only be heard on keypads programmed to sound the chime tone. See MENU Note 6-1-5 — Chime Tone Bosch Security Systems 10/22 BLCC615I...

  • Page 53: Chime Mode

    Reset Alarm Memory  Duress Allowed Press OK ON OFF MENU  3) Repeat Step 2 until all options are programmed as required, then press [OK] to save and exit or press [MENU] to exit without saving. Bosch Security Systems 10/22 BLCC615I...

  • Page 54: Input Options

    Burglary instant and/or handover common area. See MENU 7-7-1 — Area Options to zones can handover pulses to other burglary instant and/ enable the common area. or handover zones. 24 hour non-fire zone types can only Bosch Security Systems 10/22 BLCC615I...

  • Page 55: Senior Watch In Minute

    An exit error occurs when an entry/exit delay zone becomes unsealed during the exit delay time and remains unsealed at the end of exit delay time. If this happens, the entry delay will start. If the area is not Bosch Security Systems 10/22 BLCC615I...

  • Page 56: Alarm Key/Sw Tamper

    Smart lockout allows a previously locked zone to when a silent burglary zone has triggered an alarm. reactivate during the siren run time when a new alarm event occurs. Fire Alarm When selected, the panel will activate the strobe output Bosch Security Systems 10/22 BLCC615I...

  • Page 57: Keyfob On/Off

    00 - Disabled Press  0-9 OK to SAVE 2) Use the arrow and number keys to select the time zone that you want the area to follow, then press [OK] to save and exit. Bosch Security Systems 10/22 BLCC615I...

  • Page 58: Area Reporting

    A2 Area 2 Name A3 Area 3 Name Press  OK or MENU 2) Highlight the area required to change, then press [OK] to select. The keypad will display the current exit time set for the area selected. Bosch Security Systems 10/22 BLCC615I...

  • Page 59: Exit Time

    The keypad will sound the hi/lo tone for a period of 60 seconds before the control panel sound an alarm or until the user turns the area off. Bosch Security Systems 10/22 BLCC615I...

  • Page 60: Auto Arm Pre-Alert

    2) Using the numeric keys, enter the new senior watch time has expired, the area will automatically turn All On. time. Valid times are 001 to 255 hours. 000 = No Senior Watch Time. During the auto arm pre-alert time, the keypads assigned 6-10 Bosch Security Systems 10/22 BLCC615I...

  • Page 61: Area Testing

    2) Using the numeric keys, enter the number of days between each user test interval. Valid entries are 1 – 255 days or 000 to disable. 3) Press [OK] to save and exit or press [MENU] to exit without saving. 6-11 Bosch Security Systems 10/22 BLCC615I...

  • Page 62: Test Options

    Walk Test Fire This option allows 24-hour fire zone assigned to the corresponding area to be tested during walk test. » » E N D S E C T I O N « « 6-12 Bosch Security Systems 10/22 BLCC615I...

  • Page 63: Input Programming

    113 to 120 113 to 120 113 to 128 121 to 128 ON OFF OFF 129 to 136 129 to 136 129 to 136 129 to 144 137 to 144 Table 17: Zones Assignments To Modules Bosch Security Systems 10/22 BLCC615I...

  • Page 64: Input Commands

    Press OK or MENU 0000000001111111 1234567890123456 NSA-ANAT-------- 3) If the zone is not bypassed, the keypad will prompt: Press  OK or MENU In the above example screen, N = Zone 01 and 06 are Normal (Sealed) Bosch Security Systems 10/22 BLCC615I...

  • Page 65: Set Chime Zones

    To Go Back Press OK 3) Press [ON] or [OFF] to toggle the zone to be monitored when chime mode is turned on then press [OK] to save and exit or press [MENU] to exit without saving. Bosch Security Systems 10/22 BLCC615I...

  • Page 66: Smoke Sensor Reset

    Report Troubles Report Bypass Reserved Reserved Report Restores Delay Reporting Zone Options Lockout Siren Silent Alarm Inverted Seal Bypass Allowed Sensor Watch Armed In Part On No EOL Required Test On Exit Table 18: Zone Defaults Bosch Security Systems 10/22 BLCC615I...

  • Page 67: Burglary Delay 1

    No Entry Delay. Zones set as Burglary Instant 1 have Exit of what state the area is in. A 24hr Medical report will be Delay and are only active when the area is armed. See Bosch Security Systems 10/22 BLCC615I...

  • Page 68: 10 - Panic 24Hr

    The 24 Hour Zone Types listed above are active 24hrs a day. They will trigger an alarm regardless of Note whether or not the system or area is in the Armed, Part Armed or Disarmed state. Bosch Security Systems 10/22 BLCC615I...

  • Page 69: Pulse Count

    Bosch Security Systems 10/22 BLCC615I...

  • Page 70: Pulse Count Time

    When using the same reader for door access as well as arming, you need to select the reader badging option MENU 6-1-4 — General Options. Badging requires that you present your token 3 times in succession within 5 seconds to arm the system. Bosch Security Systems 10/22 BLCC615I...

  • Page 71: Report Route

    Press  0-9 OK to SAVE See MENU 5-4-5 — Swinger Dialler to set the number of times a zone is allowed to trigger before being locked Bosch Security Systems 10/22 BLCC615I...

  • Page 72: Report Restores

    Inverted Seal Setting this option allows a normally-open sensor or device to operate as a normally-closed device by reversing the open/closed state of the zone loop. (eg. 7-10 Bosch Security Systems 10/22 BLCC615I...

  • Page 73: Bypass Allowed

    Both channel 1 and channel 2 can only be utilised by Bosch 3401E and 3405E sensors, allowing you to If this option is disabled the zone will not be tested utilise both internal and external contacts from the during the arming sequence and the system will arm.

  • Page 74: Delete Rf Device

    Every time you send a transmission, the number of transmissions will increment and the average of the signals with be displayed. Be sure to send a few transmissions to establish a more accurate signal measurement. 7-12 Bosch Security Systems 10/22 BLCC615I...

  • Page 75: Zone Options

    The system can send Open and Close reports based on the keyswitch operation with the zone number representing the user number in the report. 7-13 Bosch Security Systems 10/22 BLCC615I...

  • Page 76: Keyswitch Options

    Inputs > Global Input Options > Input Options  MENU 3-4-2 00 - Disabled 01 - Latching On/Off 04 - Bosch Serial Rcvr Tamper On Short 02 - Pulse On/Off 05 - Crow Serial Rcvr (TBA) Reserved 03 - Simple RF On/Off...

  • Page 77: Tamper Options

    Audible Expander Tpr [OK]. Setting this option causes the system to trigger an 2) The keypad will display the zone to be tested. audible alarm when a peripheral tamper is triggered. 7-15 Bosch Security Systems 10/22 BLCC615I...

  • Page 78: Sensor Watch Time

    Sensor Watch monitoring is only active when the area is in the disarmed state. 24 hour zone types Note cannot be monitored using the Sensor Watch feature. » » E N D S E C T I O N « « 7-16 Bosch Security Systems 10/22 BLCC615I...

  • Page 79: Output Programming

    S E C TIO N 8 Output Programming he Solution 6000-IP is capable of controlling up to 37 1) Press [MENU] + [4] + [0] + [0] and select the output you want to view from the list then press [OK].

  • Page 80: Output Array

    1 to 16. door status menu. Locked 0000000001111111 1234567890123456 Unlocked NNNNN---TF------ Unlocked By TimeZone Press  OK or MENU Open Forced Open In the above example screen, Open Too Long Bosch Security Systems 10/22 BLCC615I...

  • Page 81: Door Status

    - = Macro 03 to 08 are Disabled or Not Available 2) When finished press [OK] or [MENU] to exit. 1) Enter [MENU] + [4] + [0] + [5]. 2) Use the arrow keys to highlight the door you wish to control, then press [OK]. Bosch Security Systems 10/22 BLCC615I...

  • Page 82: Output Event Type Table

    (Op) = Output Event Assignment (Zn) = Zone Event Assignment (Ur) = User Event Assignment (Tz) = TimeZone Event Assignment (Dr) = Door Group Event Assignment (Kp) = Keypad (Rr) = Reporting Destination Table 20: Output Event Types Bosch Security Systems 10/22 BLCC615I...

  • Page 83: Output Assignments

    O U T P U T D E FAU LT TA B L E The table below list the default values for all Output parameters in the Solution 6000-IP. Outputs 1 to 4 are High current digital outputs and Output 5 is the onboard relay output. Outputs 9 to 40 are only available if the optional Output Relay Expander Boards (CM710B) are fitted.

  • Page 84: Output Properties

    This event type will cause the output to operate if the performed. panel reporting functions are manually disabled and Battery tests are performed automatically every 4 hours will reset when reporting is enabled. See MENU 5-2-1 — Bosch Security Systems 10/22 BLCC615I...
  • Page 85 28 – End Of Exit Time This event type will cause the output to operate as soon as the corresponding area is disarmed and will reset This event type will cause the output to operate Bosch Security Systems 10/22 BLCC615I...
  • Page 86 This output type follows both silent and audible zone will reset when the area is armed or when a Part On zone alarms including the following audible alarms: becomes unsealed. Panel Tamper, PIN Retry Limit, Output Missing, Keyfob Bosch Security Systems 10/22 BLCC615I...
  • Page 87 This event type will cause the output to operate when the tamper circuit on the rear of the keypad is triggered. The output will reset when a valid user PIN is entered. Bosch Security Systems 10/22 BLCC615I...
  • Page 88 61 - Door Open Too Long This output will turn on when the control panel has detected that the zone assigned to the door has not returned to normal before the end of the door open too long time. 8-10 Bosch Security Systems 10/22 BLCC615I...

  • Page 89: Event Assignment

    Open Pulsing Low Output is normally open circuit and will pulse LOW when the event occurs. The output will reset when the output event restores. Use the Time Parameter to set the pulse duration. 8-11 Bosch Security Systems 10/22 BLCC615I...

  • Page 90: Timed Outputs

    For Example you may want a strobe output manually reset. to operate for 1 hour, Either of the examples below will achieve the 1 hour time. 1 Shot Open+Retrigger Output is normally LOW and will switch to open circuit 8-12 Bosch Security Systems 10/22 BLCC615I...

  • Page 91: Pulsing Mode

    This option forces the control panel not to operate the output when a low battery or missing battery condition is in effect. Once the low battery condition restores, the output will return to normal operation. 8-13 Bosch Security Systems 10/22 BLCC615I...

  • Page 92: Door Control

    Access Route set in MENU 1-6-0. It will also appear in the keypad display as an alarm condition 00 - Disabled identifying the door 'ALARM Door 1 Name' . Press  0-9 OK to SAVE 8-14 Bosch Security Systems 10/22 BLCC615I...

  • Page 93: Alarm Door Forced

    R F O U T P U T S This opion allows the control panel to sound an alarm Solution 6000-IP control panels have the ability to add/ when a door forced events occurs It will also appear in delete and test RF outputs when using Digiflex Smart...

  • Page 94: Delete Rf Device

    To default, first power the unit, then press and hold both relay buttons down until the Green RF and Red PGM indi- cators flash rapidly, then release the buttons and the unit will have defaulted. (Approximately 10 seconds). 8-16 Bosch Security Systems 10/22 BLCC615I...
  • Page 95 MENU 4-0-6 Macro Array will show a T when the macro result is True, an F when the macro result is false and a - when the macro hasn’t been configured. The macro will be true when all conditions in the macro script have been met. 8-17 Bosch Security Systems 10/22 BLCC615I...

  • Page 96: Name

    DOOR and then create a shortcut for the DOOR. The shortcut will allow you to control the door The following example could be used to operate an output and at the same time see the condition of the door. 8-18 Bosch Security Systems 10/22 BLCC615I...
  • Page 97 [OK]. At any time you can press the [OFF] key to clear the text from the current cursor position to the end of the line. Name MA1 Macro 1 Name Press  OK to SAVE 8-19 Bosch Security Systems 10/22 BLCC615I...

  • Page 98: Scene

    Part 1 Part 2 Zone Bypass Macro (TBA) Countdown Table 24: Macros Scene Characters The following macro scene operators are available. Operator Character Operator Meaning & Inverted Function Table 25: Macro Scene Operator Characters 8-20 Bosch Security Systems 10/22 BLCC615I...

  • Page 99: Output Testing

    3) When the siren test is complete, the keypad will OK to continue display the following: Press OK or MENU Testing Complete. Press OK to continue Press OK or MENU 4) Press [OK] to exit. 4) Press [OK] to exit. 8-21 Bosch Security Systems 10/22 BLCC615I...

  • Page 100: Strobe Test

    [OK] to end the test. Testing Complete. Press OK to continue Press OK or MENU 4) Press [OK] to exit. » » E N D S E C T I O N « « 8-22 Bosch Security Systems 10/22 BLCC615I...

  • Page 101: Comms Programming

    MyAlarm web site. This number should be entered into all panels installed by the installer allowing them to view all of their panels via the MyAlarm web site. Bosch Security Systems 10/22 BLCC615I...

  • Page 102: Ras Security Pin

    Press 0-9 OK to SAVE 2) Using the numeric keys enter the new threshold limit, then press [OK] to save and exit or press [MENU] to exit without saving. There is no need to enter the % symbol. Bosch Security Systems 10/22 BLCC615I...

  • Page 103: Reporting Options

    01 - Contact ID PSTN Press  0-9 OK to SAVE 2) Use the up and down arrow keys to select the Transmission Format required then press [OK] to save and exit or press [MENU] to exit without saving. Bosch Security Systems 10/22 BLCC615I...

  • Page 104: Emergency Route

    2) Using the numeric keys, enter the new Swinger Dialler count then press [OK] to save and exit or press [MENU] to exit without saving. Valid entries are 0 - 15 / 0 = disabled. Bosch Security Systems 10/22 BLCC615I...

  • Page 105: Myalarm

    IP address in MENU 5-5-0. 09050 Press 0-9 OK to SAVE 2) Using the numeric keys, enter the IP address required, then press [OK] to save and exit, or press [MENU] to exit without saving. Bosch Security Systems 10/22 BLCC615I...
  • Page 106 Receiver IP Address, then press MyAlarm IP Address, then press [OK] to save and [OK] to save and exit or press [MENU] to exit exit or press [MENU] to exit without saving. without saving. Bosch Security Systems 10/22 BLCC615I...
  • Page 107 IP format required, then press [OK] to save and exit (destination 1 or 2) that you want to program the or press [MENU] to exit without saving. acknowledge wait time. Rr1 Dest 1 Rr2 Dest 2 Exit Press OK or MENU  Bosch Security Systems 10/22 BLCC615I...
  • Page 108 1) Press [MENU] + [5] + [6] + [6]. The keypad will prompt you to select which destination (destination 1 or 2) that you want to program the acknowledge wait time. Rr1 Dest 1 Rr2 Dest 2 Exit Press OK or MENU  Bosch Security Systems 10/22 BLCC615I...

  • Page 109: Sia Ip Prefix

    (ie. "R" or "R0" are not to to be transmitted in this 3) Highlight the destination that you want to case). program, then press [OK] to select. Bosch Security Systems 10/22 BLCC615I...

  • Page 110: Use Sia Format

    IP, this option will allow applicable events to include text with the report. 32 Bit Checksum This allows the control panel to report SIA IP using a 32 Bit checksum. Otherwise the control panel will report SIA IP using a 16 Bit checksum. 9-10 Bosch Security Systems 10/22 BLCC615I...

  • Page 111: Ip Ras Allowed

    This option allows the control panel to communicate using the UDP internet protocol (User Datagram Protocol) when the installer remotely connects via Solution Link software. If this option is not programmed, the control panel will use the TCP IP protocol. 9-11 Bosch Security Systems 10/22 BLCC615I...

  • Page 112: Udp User Ras

    [MENU] to exit without saving. 2) Using the numeric keys, enter the new IP RAS Lockout Time, then press [OK] to save and exit or press [MENU] to exit without saving. Valid entires are 0 to 255 seconds. 9-12 Bosch Security Systems 10/22 BLCC615I...

  • Page 113: Comms Testing

    3) If the test fails, the keypad will prompt: arrow keys to change the time from am to pm. Note Test Report Failed.. Please Call For Service Press OK or MENU 4) Press [OK] or [MENU] to exit. 9-13 Bosch Security Systems 10/22 BLCC615I...

  • Page 114: Test Report Period

    [ON] key to enable or the [OFF] key to disable. 3) Repeat Step 2 until all options are programmed as required, then press [OK] to save and exit or press [MENU] to exit without saving. 9-14 Bosch Security Systems 10/22 BLCC615I...
  • Page 115 Op1 OutputX Exp 2 Ux1 UniExpander 1 Press  OK or MENU 2) The status line will scroll the keypad voltage, temperature and area while the device type and firmware version number are continuously displayed. 10-1 Bosch Security Systems 10/22 BLCC615I...

  • Page 116: Lan Scan

    010 Kp1 Keypad 5 Name Note type keypads when adjusting the keypad contrast Press  OK or MENU settings. In version 2.16, this has been corrected. 2) Press [OK] or [MENU] to exit. 10-2 Bosch Security Systems 10/22 BLCC615I...

  • Page 117: Keypad Backlight

     Disarming Allowed Press OK ON OFF MENU  3) Repeat Step 2 until all options are programmed as required, then press [OK] to save and exit or press [MENU] to exit without saving. 10-3 Bosch Security Systems 10/22 BLCC615I...

  • Page 118: Part On Arming Allowed

    Selecting this option allow the user to turn the area All reader has been assigned to. See MENU 6-1-3 — Home On or Part On/Part 2 On from the keypad or LAN reader Area. with no exit time. 10-4 Bosch Security Systems 10/22 BLCC615I...

  • Page 119: Pin To Change Area

    DIP switches on the keypad and each keypad must If the option is programmed, the keypad will display as Note have a home area programmed to operate correctly. below: Area 1 is the default home area for all keypads. 10-5 Bosch Security Systems 10/22 BLCC615I...

  • Page 120: Reader Area Control

    Turns On All User Areas Opens Door + Extinguish Present Finger and Hold Turns Part On All User  Greetings Areas Display Temperature Table 29: Fingerprint - Non Badging Examples Press  OK ON OFF MENU 10-6 Bosch Security Systems 10/22 BLCC615I...

  • Page 121: Extinguish

    The above options can be configured independantly for each keypad fitted to the system. 1) Press [MENU] + [6] + [1] + [6] and use the up and down arrows to highlight the keypad in the list then press [OK]. 10-7 Bosch Security Systems 10/22 BLCC615I...

  • Page 122: Audible Keypad Fire

    Emergency Alarm has been triggered via the keypad. LAN reader to. 3) Press [OK] to save and exit or press [MENU] to exit without saving. 10-8 Bosch Security Systems 10/22 BLCC615I...

  • Page 123: Lockout Time

    DHCP then you should enter the assigned IP address for the Wi-Fi keypad here. You will also need to enter the Subnet Mask and Default Gateway addresses. Subnet Mask Only enter when not using DHCP. Default Gateway Only enter when not using DHCP. 10-9 Bosch Security Systems 10/22 BLCC615I...
  • Page 124 Bosch Compatible has been added to allow the panel to work 1) Press [MENU] + [6] + [2] + [0]. The keypad will with both DF SMART RF devices and Bosch devices at the same display the current receiver options.
  • Page 125  Report RF Low Battery Press  OK ON OFF MENU 2) Use the up and down arrow keys to highlight the option then press the [ON] key to enable or the [OFF] key to disable. 10-11 Bosch Security Systems 10/22 BLCC615I...
  • Page 126 The following button functions are currently available. 3) To test another transmitter, repeat step 2. A beep will be heard each time a new RFID is received and the new number will be displayed. 10-12 Bosch Security Systems 10/22 BLCC615I...
  • Page 127  Display Troubles the serial number of the control panel. Use keys [0] - [9]  Report Troubles to program RF Site Key + [OK] to save.  Delay Reporting Press  OK ON OFF MENU 10-13 Bosch Security Systems 10/22 BLCC615I...
  • Page 128 NB IOT, 2G or 3G fallback. See Alpha Text Programming in Section 4 — Reserved Programming Overview for further detail on entering Not used leave disabled. Note alpha text. 10-14 Bosch Security Systems 10/22 BLCC615I...
  • Page 129 Typical subnet mask is 255.255.255.0. 1) Press [MENU] + [6] + [6] + [1]. The keypad will display the current subnet mask. 10-15 Bosch Security Systems 10/22 BLCC615I...
  • Page 130 Only one ethernet module can be fitted per panel. 1) Enter your Installer PIN + [MENU]. 2) Enter [6] + [6] + [9] + [OK]. The keypad will display the current options which are selected or enabled. 10-16 Bosch Security Systems 10/22 BLCC615I...
  • Page 131 The panel number that you are getting information from list then press [OK]. (eg. Node 1 = Panel 1 etc). The Solution 6000-IP is only configured to work with one panel. System Trbl...
  • Page 132 This trouble message will display if the panel detects the from the system. RF receiver is missing or disconnected. The trouble will clear when the receiver is reconnected. 11-2 Bosch Security Systems 10/22 BLCC615I...
  • Page 133 [] and [] keys to view the Battery Trouble pages within the event. The control panel has detected that the real time clock 4) Press [OK] or [MENU] to exit. module has a low or missing backup battery. 11-3 Bosch Security Systems 10/22 BLCC615I...
  • Page 134 The log will also show the actual time a report was sent. Template Default MENU 7-0-5  This command is RESERVED. Dest = S = Sent L = Logged P = Pending F = Failed A = Aborted 11-4 Bosch Security Systems 10/22 BLCC615I...
  • Page 135 - = TimeZones 06 to 08 and Doors 13 to 16 are Disabled or Not Available Service mode will automatically exit after 2 hours if set to do so in MENU 7-7-4 — Installer Options. Note 2) When finished press [OK] or [MENU] to exit. 11-5 Bosch Security Systems 10/22 BLCC615I...
  • Page 136 Use the left and right keys to move the cursor between the month, week and year. 3) When finished press [OK] to save and exit or press [MENU] to exit without saving. 11-6 Bosch Security Systems 10/22 BLCC615I...
  • Page 137 [ON] key to enable or the [OFF] key to disable. 3) Repeat Step 2 until all options are programmed as required, then press [OK] to save and exit or press [MENU] to exit without saving. 11-7 Bosch Security Systems 10/22 BLCC615I...
  • Page 138 If the panel fails to detect the battery, or if it measures the battery voltage below 10.2 volts, then a Battery Test Failed report will be sent. A Battery Test restore will be sent when the battery is re-connected or replaced. 11-8 Bosch Security Systems 10/22 BLCC615I...
  • Page 139 Report COMM+ O/Load Setting this option will cause the panel to send an Overcurrent Trouble report to the base station when the current load on the COMM + terminal exceeds its maximum rating of 3 Amps. 11-9 Bosch Security Systems 10/22 BLCC615I...
  • Page 140 0 = no speeker beeps. 3) Press [OK] to save and exit or press [MENU] to exit without saving. Only outputs programmed as Event Type 36, horn speaker with beeps will be effected by this menu Note option. 11-10 Bosch Security Systems 10/22 BLCC615I...

  • Page 141: Name

    Stop Time Period 3 Start Time Stop Time Period 4 This menu allows you to program the start time and stop time of each timezone period. Each timezone can have up to 4 different periods. 11-11 Bosch Security Systems 10/22 BLCC615I...

  • Page 142: Day

    (e.g. to enable Monday press [2] Tz1 24 Hour TimeZone and to disable Monday press [2] again). Tz2 TimeZone 2 Name Tz3 TimeZone 3 Name Press  OK or MENU 11-12 Bosch Security Systems 10/22 BLCC615I...

  • Page 143: Invert Logic

    1) Press [MENU] + [7] + [6] + [0] and use the up and down arrows to highlight the Holiday in the list then press [OK]. Alternatively, you can enter the Holiday number directly and press [OK]. 11-13 Bosch Security Systems 10/22 BLCC615I...

  • Page 144: System Options

    As soon as any area is turned off the system will automatically turn Area 1 off. Only one common area is available on the system. If no common area is required 11-14 Bosch Security Systems 10/22 BLCC615I...

  • Page 145: Power Up As Down

    1) Press [MENU] + [7] + [7] + [3]. The keypad will display the current temperature settings. Ignore Trouble On Arm This option allows the control panel to ignore unsealed zones and trouble conditions when a user arms an area. 11-15 Bosch Security Systems 10/22 BLCC615I...

  • Page 146: Installer Options

    2) Use the up and down arrow keys to highlight the the installer PIN is not know then the panel will need to option then press the [ON] key to enable or the be returned to Bosch Security for defaulting. A charge [OFF] key to disable. applies for this service.

  • Page 147: Language

    To clear all text from the cursor position to the right, press the [OFF] key. 3) When the site name is complete, press [OK] to save and exit, or press [MENU] to exit without saving. 11-17 Bosch Security Systems 10/22 BLCC615I...

  • Page 148: System Testing

    To Go Back Press OK 4) Press [OK] to save and exit or press [MENU] to exit without saving. 2) Press [OK] to exit. » » E N D S E C T I O N « « 11-18 Bosch Security Systems 10/22 BLCC615I...
  • Page 149 ™ Opening a Garage Door using a Single Digit Code. Procedure ™ Opening a Garage Door using a 4 Button Keyfob. 1) Set RF Receiver Type in MENU 3-5-0 = 04 - Bosch ™ Auto Arming an Area using a Timezone. Serial Rcvr ™...

  • Page 150: Auto Arming An Area Using A Timezone

    1-4-5 as 4. the LAN reader to access the door. 6) Add a token to User 4 in MENU 1-2-0. 7) Exit programming mode and present the token to the LAN reader to access the door. 12-2 Bosch Security Systems 10/22 BLCC615I...

  • Page 151: Door Auto Lock/Unlock By Timezone

    Setting User Door Assignment 14) In MENU 1-4-5. assign each user to the door being used as required. Each user can be assigned to multiple doors. 15) Program the users PIN, token, fingerprint as required. 12-3 Bosch Security Systems 10/22 BLCC615I...
  • Page 152 Solution 6000-IP Installation Manual Programming Examples   This page left intentionally blank 12-4 Bosch Security Systems 10/22 BLCC615I...

  • Page 153: Specifications

    RF120 - Smart RF LAN Base Station Receiver 2-Way 3 years from date of manufacture ♦ RF121 - Smart RF LAN Base Station Receiver With 4 Relay Outputs 2-Way ♦ RF160 - Smart RF 2 Channel Wireless Output Module 13-1 Bosch Security Systems 10/22 BLCC615I...
  • Page 154 1 x Black Battery Lead 2 x 2-Way Shunts With Handle 10 x 3K3 – 0.25W +/- 1% Metal Film Resistors 10 x 6K8 – 0.25W +/- 1% Metal Film Resistors 1 x 3-Way Removable Terminal Block 13-2 Bosch Security Systems 10/22 BLCC615I...
  • Page 155 Solution 6000-IP Installation Manual Specifications   This page left intentionally blank 13-3 Bosch Security Systems 10/22 BLCC615I...
  • Page 156 F.01U.403.613 F.01U.359.721 Copyright © 2022 — In the interest of ongoing product improvement we reserve the right to change specif ications at any time without notice — E&OE — Solution 6000-IP Product Matrix 10/2022 13-4 Bosch Security Systems 10/22 BLCC615I...
  • Page 157 F.01U.275.894 F.01U.276.910 Copyright © 2022 — In the interest of ongoing product improvement we reserve the right to change specif ications at any time without notice — E&OE — Solution 6000-IP Product Matrix 10/2022 13-5 Bosch Security Systems 10/22 BLCC615I...
  • Page 158 Solution 6000-IP Installation Manual Specifications   This page left intentionally blank 13-6 Bosch Security Systems 10/22 BLCC615I...

  • Page 159: Index

    Account # ........6-8 14-1 Bosch Security Systems 10/22 BLCC615I...
  • Page 160 Poll Rate ........9-7 14-2 Bosch Security Systems 10/22 BLCC615I...
  • Page 161 Log Threshold ........9-2 14-3 Bosch Security Systems 10/22 BLCC615I...
  • Page 162 Part On ......... 6-4 14-4 Bosch Security Systems 10/22 BLCC615I...
  • Page 163 Door Assignment ....... 7-9 14-5 Bosch Security Systems 10/22 BLCC615I...
  • Page 164 Bosch Security Systems Level 2, 21 Solent Circuit Baulkham Hills, NSW 2153 Australia Phone: 1300 026 724 www.boschsecurity.com.au © 2022 Bosch Security Systems BLCC615I Issue FTR1.2...

This manual is also suitable for:

Cc615gwfCc615pb

Table of Contents
