ICM and ICMTS Motorized Valves with ICAD Actuators

Supply voltage

24 V DC (Tolerances; see
Table 2: Load
ICAD 600B, ICAD 600B-TS
24 Volt DC ONLY
CAUTION:
Please observe cable voltage drop
Please observe cable voltage drop. Distance between the applied DC transformer and the ICAD terminal box may
cause a voltage drop. Cross section of cables and size of DC transformer must be calculated so that the voltage at
all time at the ICAD terminal box
Table 3: ICAD Supply voltage tolerances
Prefabricated ICAD cable length Code number
Voltage ICAD terminal
(600B/1200B) [V DC]

Fail safe supply

24 V DC (Tolerances; see
Table 4: Load
ICAD 600B, ICAD 600B-TS

Data communication

RS-485: It is important that the installation of the data communication cable is done correctly. Remember
termination at the bus termination. Max length of cable: 1200 m with speci c cable and limited data rate. Follow
RS-485 standard.
Insulation from power supply input, metallic part and interface output: 500 V DC: For input/output connections.

Analog Input - Current or Voltage

Table 5: Current
Input range
Max input range
Input resistance
Measurement error
Reverse polarity protection
Overcurrent protection
Table 6: Voltage
Input range
Max input range
Measurement error
Reverse polarity protection
1
Do not measure inside the ICAD itself (value can be checked in ICAD menu)
© Danfoss | Climate Solutions | 2024.01
Table 3)
ICAD 1200B
(1)
, both during standstill and during operation of ICAD, is within this range:
1.5 m
027H0426
21
Min.
Max.
Table 3)
ICAD 1200B
3 m
027H0438 027H0427
22
26.4
0/4 – 20 mA
0 – 24 mA
120 Ω + diode voltage 0.7 V DC
<±1.5% of the full scale
yes
yes
0/2 – 10 V DC
0 – 12 V DC
<±1.5% of the full scale
yes
1.2 A
2.0 A
10 m 15 m
027H0435
23 24
1.2 A
2.0 A
BC465027827472en-000102 | 9
