Status/Next Service

Parameter Description and selection
Label ID
name options
Once the service interval has
passed, and Time to next
service (ID50) has reached 0,
the time overdue is calcula-
Time overdue ted. Time is updated every
ID233
30 minutes and calculated
as full days (24 hours) based
on runtime. 0...32764 (in
days)
Readout the days remaining
of the current service inter-
val (ID234). Time is updated
Time to next
ID50 every 30 minutes and calcu-
service
lated as full days (24 hours)
based on runtime. 0...999
(in days)
Readout the run time in full
hours for the ICAD from
when it was rst powered on
Run time
ID48
or factory reset. Saved every
30min 0...4294967293 (in
minutes)

Status/Supply

Parameter Description and selection
Label ID
name options
Readout the current power
supply voltage to ICAD in
Power supply
Volt. 0...300 points, where 10
ID228
voltage (V)
= 1V (I.e. 234 = 23.4V; 100 =
10.0V)
Readout the state of the
UPS. Only active when UPS
supply (ID21) is set to yes
UPS health and the UPS setting (ID22) is
ID227
not set to o .
1: OK;
0: Poor
© Danfoss | Climate Solutions | 2024.01
Factory set‐
Min. Max.
ting
0 32764 0
0 999 365
0 4294967293 0
Factory set‐
Min. Max.
ting
0 300 0
0 1 0
Pass‐
Alterna‐
word
Modbus tive Size in
level to
address Modbus bytes
Read -
address
Write
3063 3350 2 1
3064 3351 2 1
3060 ... 3347 ...
4 1
3061 3348
Pass‐
Alterna‐
word
Modbus tive Size in
level to
address Modbus bytes
Read -
address
Write
3054 3336 2 1
3052 3335 1 1
BC465027827472en-000102 | 28
Read
only
(RO) /
Persis‐ Modbus
Read
tent func‐
Write
Yes/No tion
(RW) /
Write
(W)
RO Yes 3
RO Yes 3
RO Yes 3
Read
only
(RO) /
Persis‐ Modbus
Read
tent func‐
Write
Yes/No tion
(RW) /
Write
(W)
RO No 3
RO No 3
