Status/Read Outs Parameters - Danfoss ICM User Manual

ICM and ICMTS Motorized Valves with ICAD Actuators

Status/Read Outs Parameters

Parameter Description and selection
Label ID
name options
Readout the main switch
state of ICAD.
Main switch
ID1 2: con g;
1: manual;
0: auto
Readout ICAD mode
2: 3 – point;
ID2 Mode
1: on/o ;
0: modulating
Readout the valve con gura-
tion for ICAD.
12: ICADTS ICMTS 50/80;
11: ICADTS ICMTS20;
10: Pilot Valve CVE;
9: ICAD1200B ICM150;
8: ICAD1200B ICM125;
Valve
7: ICAD1200B ICM100;
ID8
con guration
6: ICAD1200B ICM65;
5: ICAD1200B ICM50;
4: ICAD1200B ICM40;
3: ICAD600B ICM32;
2: ICAD600B ICM25;
1: ICAD600B ICM20;
0: not con gured
Readout the analog input
when the operation mode
(ID2) is set to modulating
and the input signal (ID3) is
AI (current,
set to use current (0-20mA
ID34
mA)
or 4-20mA) 0...22000 points,
where 1000 = 1mA (I.e.
10031 = 10.031mA; 7062 =
7.062mA)
Readout the analog input
when the operation mode
(ID2) is set to modulating
AI (voltage, and the input signal (ID3) is
ID35
V) set to use voltage (0-10V or
2-10V) 0...12000 points,
where 1000 = 1V (I.e. 1291 =
1.291V; 10372 = 10.372V)
Readout the analog output
when AO signal output
(ID18) is set to use (0-20mA
AO (current,
or 4-20mA) 0...22000 points,
ID36
mA)
where 1000 = 1mA (I.e.
10031 =10.031mA; 7062 =
7.062mA)
Readout of Uninterruptible
Power Supply (UPS) is ap-
plied to the ICAD. This ena-
ID21 UPS supply
bled A4 alarms (Low voltage
of UPS supply). 1: yes;
0: no
Readout of the requested
valve position for safe state.
Safe state occurs for A2, A3,
A5, A8, A10, and can be a re-
sult of the boosting process
Emergency
during A9. 3: emergency
ID20
state
opening degree (set posi-
tion to ID27)
2: maintain position;
1: open valve;
0: close valve;
© Danfoss | Climate Solutions | 2024.01
Factory set‐
Min. Max.
ting
0 2 0
0 2 0
0 13 0
0 22000 0
0 12000 0
0 22000 0
0 1 0
0 3 0
Pass‐
Alterna‐
word
Modbus tive Size in
level to
address Modbus bytes
Read -
address
Write
3055 3337 1 1
3001 3301 1 1 - 2
3056 3338 1 1
3041 3325 2 1
3042 3326 2 1
3043 3327 2 1
3023 3308 1 1 - 2
3022 3319 1 1 - 2
BC465027827472en-000102 | 29
Read
only
(RO) /
Persis‐ Modbus
Read
tent func‐
Write
Yes/No tion
(RW) /
Write
(W)
RO No 3
RW Yes 3 & 6, 16
RO No 3
RO No 3
RO No 3
RO No 3
RW Yes 3 & 6, 16
RW Yes 3 & 6, 16
