Non-Displayed Parameters - Danfoss ICM User Manual

ICM and ICMTS Motorized Valves with ICAD Actuators

Non-displayed Parameters

Parameter Description and selection
Label ID
name options
Manage the time elapsed
without user actions before
the built-in display of ICAD
Screen saver
ID55
goes to sleep mode (in sec-
onds). Pressing any button
ends the screen saver mode
Readout the current ICAD
status
6: Con g: ICAD continues to
operate as before. In con g
mode parameters can be
changed but are not applied
until setting main switch
back to auto or manual
5: Valve detection: ICAD is
currently detecting a valve
4: Safe state: ICAD has stop-
Status ped operation and applied
ID226
the emergency state setting
(ID20) 3: Boost: ICAD is cur-
rently boosting to achieve
the requested position
2: Calibration: ICAD is cur-
rently calibrating
1: Manual: User manually
sets the valve position to be
maintained
0: Auto: Input signal type
(ID3) controls valve position
Readout the opening degree
(OD).
OD by encoder when encod-
er operation (ID15) is on,
Current OD else OD by internal counter.
ID33
0...10000 points, where 100
= 1%
(I.e. 5219 = 052.19%; 10000
= 100.00%)
Readout the requested
opening degree automati-
cally matching the settings
Requested for input type and operation
ID211
OD mode. 0...10000 points,
where 100 = 1%
(I.e. 5219 = 052.19%; 10000
= 100.00%)
Readout the current access
level corresponding to user
login. This manages rights
for reading and writing pa-
Current
rameters, and controls what
ID254
access level
the user sees
3:Danfoss Admin;
2: Service;
1: Read only
Readout the current voltage
of the UPS battery, when
Battery this is attached and enabled.
ID239
voltage 0...300 points, where 10 = 1V
(I.e. 234 = 23.4V; 100 =
10.0V)
© Danfoss | Climate Solutions | 2024.01
Factory set‐
Min. Max.
ting
30 1200 360
0 6 0
0 10000 0
0 10000 0
1 3 1
0 300 0
Pass‐
Alterna‐
word
Modbus tive Size in
level to
address Modbus bytes
Read -
address
Write
3090 3380
2 1 - 2
3051 3322
1 1
3040 3323
2 1
3053 3324
2 1
3058 3340
1 1-2
3059 3341
1 1
BC465027827472en-000102 | 36
Read
only
(RO) /
Persis‐ Modbus
Read
tent func‐
Write
Yes/No tion
(RW) /
Write
(W)
3 & 6,
RW Yes
16
RO No
3
RO No
3
RO No
3
RW No
3
RO No
3
