AFBR-S50 User Guide

Evaluation Kit Quick Start Guide

1.3 Updating the Device Software

When updating the AFBR-S50 SDK, the software on the evaluation kit must also be updated manually to match the installed

GUI. This is done from the AFBR-S50 Explorer application by performing the following steps:

Step 1: Install the desired device software, as described in

Software

Setup, and open the AFBR-S50 Explorer app.

Step 2: Connect the red AFBR-S50 evaluation board via the OpenSDA interface to the PC. An additional driver is not

required.

Figure 5: Connecting the Red Evaluation Board with OpenSDA Labeled on the Bottom Side

Step 3: In the Explorer app, select Help > Flash Device Software > Flash..._USB.srec, and wait until the device is

successfully flashed.

Figure 6: Flash Device Software Option

NOTE:

While the red NXP board supports USB and UART, the blue STM board offers only a UART connection.

Broadcom

AFBR-S50-EK-UG104
