2.2 Menu Bar

The AFBR-S50 Explorer menu bar includes the following three menus:
Device

View

Help

Figure 12: Device Menu
From the Device menu, options are available to open and close the USB connection, trigger measurements, create a log
data file via a data logger to store measurement data, monitor and store the communication of the serial interface, and, once
connected, reset the microcontroller on demand.
All data measured by the ToF sensor device can be logged to a file for plotting and evaluating the measurement results. The
log file is saved to the entered path.
Figure 13: Data Logging Options
