1.3 Updating the Device Software

When updating the AFBR-S50 SDK, the software on the evaluation kit must also be updated manually to match with the
installed GUI. This is done from the AFBR-S50 Explorer App by performing the following steps:
Step 1: Install the desired device software, as described in Hardware and Software Setup, and open the AFBR-S50 Explorer
App.
Step 2: Connect the red AFBR-S50 evaluation board via the OpenSDA interface to the PC. An additional driver is not
required.
Figure 5: Connecting the Red Evaluation Board with OpenSDA Labeled on the Bottom Side
Step 3: In the explorer App, go to menu Help > Flash Device Software > Flash..._USB.srec, and wait until the device is
successfully flashed.
Figure 6: Flash Device Software Option
Step 4: When flashed successfully, connect the device using the USB port labeled with KL46Z, and run it as described in
the following section.
