Paper performance guidelines
Stock type
Non-tearing 3-hole
Non-tearing
Xerox carbonless paper
3-hole drilled, edge
reinforced dual-purpose
Transparencies—
Oversized (8.5 by 14 inches,
0.5 inch white stripe/216 by
356 mm, 1 mm white strip)
Preprinted stock
Transparencies—
Paper-backed,
high-speed,
removable stripe
Tab stock
9-inch cover stock
110 pound/200 gsm
High-speed label stock
B-4
Table B-4. Paper stocks guide (Continued)
Instructions for use
• Load in trays 1 and 2 only.
• Load with holes to the RIGHT.
• DO NOT run two-sided (duplex) prints.
• Load in trays 1 and 2 only.
• DO NOT run two-sided (duplex) prints.
• Load paper in trays 3, 4, 5 and 6 only.
• Only Xerox carbonless paper is recommended for high speed
Xerographic equipment.
• Use trays 1 and 2.
• Load paper with holes to the right, reinforced side DOWN.
• In two-sided (duplex) printing, degraded print quality may occur
near the reinforcement.
• Leave stock in wrapper until use to achieve maximum stock
flatness.
• Run with no more than 200 sheets in a tray.
• Load with the white stripe to the RIGHT in trays 1 and 2 ("shiny"
side UP for best performance).
• Simplex only.
Certain types of ink or insufficient drying time may cause the ink to
adhere to various machine components and printed sheets. Allow at
least 3 hours of drying time before using preprinted stock.
CAUTION: Certain preprinted stocks lie unevenly in the feeder trays. If
the right side of the stack is higher than the left in trays 3, 4, 5 and 6
SEVERE hardware damage can occur. Load the stock in trays 1 or 2
or load fewer sheets.
• High-speed paper-backed transparencies may be run from trays 1
and 2 with paper side DOWN.
• Run no more than 50 removable stripe transparencies at one time.
• Load the transparencies on top of approximately 50 sheets of
paper.
• Load into trays 1 and 2 with tabs to the LEFT.
• For best performance, print should be centered on the tab and
should not extend to either edge.
• Use tab stock in perfectly flat condition. DO NOT use deformed,
bent, or damaged tabs.
Load into any tray.
• Load FACE UP.
• DO NOT run two-sided (duplex) prints.
