The selected boot mode is shown in the table below:
Table 12 DIP switch set boot mode
Mode
Switch
SW state setting
Note: The switch is facing up, it is ON state, the switch is facing down, it is OFF state.

2.3.11. Slot

DEBIX Infinity provides a Micro SD slot (J1), set the DIP switch to "011" (Micro SD card boot
mode), Micro SD card can be used as a system boot card, insert the Micro SD card with the
system installed here, and then power on device to start the system in the Micro SD card.
When the DIP switch is set to other modes and the device is power on, the Micro SD card can
be used as a standard memory card to save user data.

2.4. Packing List

DEBIX Infinity (default without eMMC)

www.debix.io
USB eMMC
Figure 23 Micro SD slot
Polyhex Technology Company Limited
Micro SD Nor Flash
